- 1. Introduction
- 2. Unit Description
- 3. Getting Started
- 4. Hardware Installation
- 5. Basic Configuration
- 5.1. Communicating with the VMR or NPS Unit
- 5.2. Configuration Menus
- 5.3. Defining System Parameters
- 5.4. User Accounts
- 5.5. Managing User Accounts
- 5.6. The Plug Group Directory
- 5.7. Defining Plug Parameters
- 5.8. Serial Port Configuration
- 5.9. Network Configuration
- 5.10. Save User Selected Parameters
- 6. Reboot Options
- 7. Alarm Configuration
- 8. The Status Screens
- 9. Operation
- 10. SSH Encryption
- 11. Syslog Messages
- 12. SNMP Traps
- 13. Operation via SNMP
- 14. Setting Up SSL Encryption
- 15. Saving and Restoring Configuration Parameters
- 16. Upgrading VMR/NPS Firmware
- 17. Command Reference Guide
- Appendix A. Specifications
- Appendix B. Interface Descriptions
- Appendix C. Customer Service
- Index
1-2
Introduction
Model Numbers
The VMR series and NPS series include a variety of horizontal and vertical models to
accommodate the power distribution needs of almost any rack mount application.
VMR Series
Model No.
Input
Feeds
Input
Voltage
Max. Load
per Outlet
Max. Load
per Input
Max. Load
per Unit
VMR-4HS15-1 1 ea, 15 Amp 100 to 120 VAC 12 Amps 12 Amps* 12 Amps*
VMR-4HS15-2 1 ea, 15 Amp 100 to 240 VAC 10 Amps 12 Amps* 12 Amps*
VMR-8HS20-1 1 ea, 20 Amp 100 to 120 VAC 15 Amps 16 Amps* 16 Amps*
VMR-8HS20-2 1 ea, 20 Amp 100 to 240 VAC 10 Amps 16 Amps* 16 Amps*
VMR-8HS16-3 1 ea, 16 Amp 200 to 240 VAC 10 Amps 16 Amps 16 Amps
VMR-8HD20-1 2 ea, 20 Amp 100 to 120 VAC 15 Amps 16 Amps* 32 Amps*
VMR-8HD20-2 2 ea, 20 Amp 100 to 240 VAC 10 Amps 16 Amps* 32 Amps*
VMR-8HD16-3 2 ea, 16 Amp 200 to 240 VAC 10 Amps 16 Amps 32 Amps
VMR-16HD20-1 2 ea, 20 Amp 100 to 120 VAC 15 Amps 16 Amps* 32 Amps*
VMR-16HD20-2 2 ea, 20 Amp 100 to 240 VAC 10 Amps 16 Amps* 32 Amps*
VMR-16HD16-3 2 ea, 16 Amp 200 to 240 VAC 10 Amps 16 Amps 32 Amps
NPS Series
Model No.
Input
Feeds
Input
Voltage
Max. Load
per Outlet
Max. Load
per Input
Max. Load
per Unit
NPS-8HS20-1 1 ea, 20 Amp 100 to 120 VAC 15 Amps 16 Amps* 12 Amps*
NPS-8HS20-2 1 ea, 20 Amp 100 to 240 VAC 10 Amps 16 Amps* 12 Amps*
NPS-8HS16-3 1 ea, 16 Amp 200 to 240 VAC 10 Amps 16 Amps 16 Amps
NPS-8HD20-1 2 ea, 20 Amp 100 to 120 VAC 15 Amps 16 Amps* 32 Amps*
NPS-8HD20-2 2 ea, 20 Amp 100 to 240 VAC 10 Amps 16 Amps* 32 Amps*
NPS-8HD16-3 2 ea, 16 Amp 200 to 240 VAC 10 Amps 16 Amps 32 Amps
NPS-16HD20-1 2 ea, 20 Amp 100 to 120 VAC 15 Amps 16 Amps * 32 Amps*
NPS-16HD20-2 2 ea, 20 Amp 100 to 240 VAC 10 Amps 16 Amps * 32 Amps*
NPS-16HD16-3 2 ea, 16 Amp 200 to 240 VAC 10 Amps 16 Amps 32 Amps
* In accordance with UL requirements for branch circuits, this value has been
de-rated to 80%.
Typographic Conventions
^ (e.g. ^X) Indicates a control character. For example, the text "^X" (Control X)
indicates the [Ctrl] key and the [X] key must be pressed
simultaneously.
COURIER FONT Indicates characters typed on the keyboard.
For example, /AC or /ON A2.
[BoldīFont] Text set in bold face and enclosed in square brackets indicates a
specific key. For example, [Enter] or [Esc].
< > Indicates required keyboard entries. For Example: /P <n>.
[ ] Indicates optional keyboard entries. For Example: /P [n].
