Specification Sheet

2008
2008
800.575.2658
www.weslock.com
Finishes
Antique Brass (A)
PVD (B)
Polished Brass (3)
Satin Chrome (D)
*Satin Nickel (N)
**Oil Rubbed Bronze (1)
Finishes
Antique Brass (A)
PVD (B)
Satin Chrome (D)
Satin Nickel (N)
*Oil Rubbed Bronze (1)
Fold
OVAL
MODEL 372
Entry Handle Features
• 5-pin Cylinder
• Zinc diecasted
• 1” throw deadbolt with two hardened steel rollers -
prevents sawing
Entry Handle Specifications
• Adjusts to door thickness from 1-3/4” to 2”
• Optional door thickness 2” to 2-1/4”
• Adjustable latches 2-3/8” or 2-3/4” with removable faceplates
• Fits doors prepared with 2-1/8” Top and 2-1/8” Bottom cross
holes and 1” edge hole
• 5-1/4” minimum center to center cross hole spacing
Entry Handle Warranty
• Limited Lifetime Mechanical Warranty
• Limited 10 Year Finish Warranty
• Lifetime PVD Finish on exterior Polished Brass
MODEL 371
Essentials Collection
ENTRY HANDLES & DEADBOLTS
LEXINGTON
TM
Knob & Lever Features
• Cylindrical Door Locks
• Meets ANSI A 156.2 Grade II lock standards
• 5-pin Cylinder
• Locksets have pre-installed installation screws, which are
concealed behind a snap-on rosette
• Removable knobs/levers prevents scratching during installation
• Panic-Proof Keylock/Privacy - one turn of interior knob/lever
unlocks & opens door
• Push Button locking in Rosette
• Weslock Keyway standard (Optional Schlage and Kwikset Keyways)
• Zinc diecasted levers
• All brass knobs & rosettes
• ADA compliant levers
Knob & Lever Specifications
• Adjustable Latches 2-3/8” or 2-3/4” with removable faceplates
• Fits doors prepared with 2-1/8” cross hole & 7/8” or 1” edge hole
• Latch diameter is 7/8”
• For 1” edge hole, non-mortise application requires metal sleeve
(part # 70991)
• Adjusts to door thickness from 1-3/8” to 1-3/4”
• Optional door thickness from 1-3/4” to 2-1/4”
Knob & Lever Warranty
• Limited Lifetime Mechanical Warranty
• Limited 10 Year Finish Warranty
• Lifetime PVD Finish on exterior Polished Brass Keylock function
SONIC
TM
BARRINGTON
TM
Essentials Collection
KNOBS & LEVERS
PROVENCE
Deadbolt Features
• Heavy duty security strike with 3” screws
• 5-pin Cylinder
• 1” throw deadbolt with two hardened steel rollers -
prevents sawing
• Weslock Keyway standard (Optional Schlage Keyway)
• ADA recommended, extra large interior thumbturn
Deadbolt Specifications
• Adjustable latches 2-3/8” or 2-3/4” with removable faceplates
• Fits doors prepared with 2-1/8” cross holes and 1” edge hole
• Adjusts to door thickness from 1-3/8” to 2”
• Optional door thickness from 2” to 2-1/4”
Deadbolt Warranty
• Limited Lifetime Mechanical Warranty
• Limited 10 Year Finish Warranty
• Lifetime PVD Finish on exterior Polished Brass
* Special order for Sonic
TM
** Special order only for Barrington
TM
and Provence
* Special order finish.
Finishes
Antique Brass (A)
PVD (B)
Satin Chrome (D)
Bright Chrome (6)
Satin Nickel (N)
Weathered Pewter (P)
Oil Rubbed Bronze (1)
Black (2)
