Datasheet
Techn. datasheet
Midi Horns and Sirens / EvoSIGNAL
Midi Sounder 12/24VAC/DC GY
!
For additional installation and mounting information, refer to the appropriate user guide at www.werma.com. This
printed copy is for information only and is subject to alteration.
WERMA Signaltechnik GmbH + Co. KG · Dürbheimer Straße 15 · D-78604 Rietheim-Weilheim
Tel +49(0) 74 24 95 57-0 · Fax +49(0) 74 24 95 57-44 · info@werma.com · www.werma.com
1/2
08.01.2020 / 161.700.70
Part No.: 161.700.70
Series: EvoSIGNAL Midi
MECHANICAL DATA
Height 78 mm
Diameter 85 mm
Materials PC
PC/ABS
Housing colour Grey
Protection category IP66
Connection Push-in terminal
cross-sectional area minimum 0,25mm² / 24AWG
cross-sectional area maximum 1,50mm² / 16AWG
Acoustic service life 5,000 h minimum
Working temperature minimum -30°C
Working temperature maximum +60°C
UL Type Rating Type 12
Weight with packaging 178 g
Product weight 140 g
ELECTRICAL DATA
Operating voltage 12V
24V
Operating voltage type AC/DC
Operating voltage type 50Hz
Operating voltage tolerance +/- 10%
Rated operational voltage 12 VDC
Rated operational current 135 mA
Rated inrush current 2,5A
Protection class Protection class 2
Pollution degree 3
Overvoltage category III
ACUSTICAL DATA
Volume/dB(max) at 1m distance 110,0 dB (A)
Acoustic signal image Multi-tone
Number of tones 10 tone
Audio frequency 3300 Hz
