assembly:

6. Insert footrest assembly (D) into bracket (F) under the seat of the chair

and tighten knob (Y).

7. Mount footrests rods (E) onto vertical section of footrest assembly.

Mount left side first.

8. Slide foot sandals onto footrest rods and tighten bracket underneath

footrest sandal using knob (X).

9. Insert abductor (G) into round receptacle bracket (Z).

1. Remove all positioning components from box.

2. Remove bolts (A) and insert back mounting bracket (AG) in the

following order:

- Flat retaining bracket (AI)

- Seat pan (AH)

- Back mounting bracket (AG)

- Flat retaining bracket (AI #2)

Reinsert bolts.

3. Lift up back to desired angle and seat depth and tighten bolts (A).

4. Insert arm rest assembly into mounting brackets (C).

5. Insert laterals in bracket (B) and tighten knob (V)

10. Insert headrest post (H) into bracket (I) and turn knob (J) to tighten.

Tighten allen screws (K) on triangular bracket (L) and on the back of the

headrest cushion (M)
