MSS Tilt & Recline Item # MS 3000N EU Authorized Representative Drive Medical LTD Ainley’s Industrial Estate Elland, West Yorkshire, United Kingdom HX5 9JP www.drivemedical.com www.drivemedical.
assembly: 6. Insert footrest assembly (D) into bracket (F) under the seat of the chair and tighten knob (Y). 1. Remove all positioning components from box. 7. Mount footrests rods (E) onto vertical section of footrest assembly. Mount left side first. 2. Remove bolts (A) and insert back mounting bracket (AG) in the following order: - Flat retaining bracket (AI) - Seat pan (AH) - Back mounting bracket (AG) - Flat retaining bracket (AI #2) 8.
SEAT TO BACK ANGLE AND SEAT DEPTH adjustments: Loosen bolts (A) and position back at desired depth. Place seat to back angle at desired setting. TILT POSITION Open knob (N) and pull back securing bracket (O). Press tilt actuator (P) and press down of both push handles (Q) to desired tilt angle. Return securing bracket (O) and tighten knob (N). O A N ARM RESTS Height – Loosen bolt (R) and adjust armrest assembly. Angle – Push in knob (S) and adjust angle position. Depth – Loosen bolts (AF) and adjust.
BACK HEIGHT FOOTRESTS Back height can be adjusted by loosening knobs (U) and raising or lowering back. Height - Loosen knob (W) and raise or lower bracket. LATERALS V U Laterals can be adjusted in height and width. Loosen knob (V) and adjust height and width. Angle – Loosen knob (X). Position • Lateral position of foot sandals on rod can be achieved by loosening knob (X). • Depth position of foot sandals on rod can be achieved by loosening knob (X).
LAP BELT Length – Use buckle &/or change the position of the Velcro® straps under the seat. two year limited warranty HARNESS The top and side Velcro® straps on the back of the chair adjust the length of the straps. Your Drive brand product is warranted to be free of defects in materials and workmanship for two years from the date of the original consumer purchase. This device was built to exacting standards and carefully inspected prior to shipment.
