FEATURES & OPERATING CONTROLS
2
Fig. 1 Countertop Griddle Features & Operating Controls
G136 Shown - G196, G236, G246 and G606 are Similar
SPLASHGUARD
GREASE TROUGH
GREASE DRAWER
TEMPERATURE
CONTROL
KNOB
HEATING
INDICATOR
NAMEPLATE
111 p/n 2M-303340 OpManual Built-In Electric Griddles
TEMPERATURE
CONTROL
Power is applied to the heating elements according to the control
knob position and the actual temperature sensed at the thermobulb.
When the element is energized the heating indicator will glow.
Each section of the griddle is individually controllable.
Dial position is an indication of the temperature setting. The actual
temperature at the griddle surface will vary, depending upon the initial
type and temperature of the product, and other variables.
GREASE TROUGH
Extra-wide trough with curved corners for easier cleaning. Trough
slopes toward a large waste hole that empties into the removable
grease drawer.
GREASE DRAWER
Large-capacity drawer is removable through the front for easy
cleaning.
REMOVABLE SPLASH
GUARD
Stainless steel splash guard simplies griddle maintenance and helps
to keep grease from splattering onto adjacent walls and equipment
NAMEPLATE
Lists manufacturer’s information, model and serial number. Also lists
electrical specications.
