111 p/n 2M-303340 OpManual Built-In Electric Griddles 111 p/n 2M-303340 OpManual Built-In Electric Griddles
WARRANTY xi
SPECIFICATIONS 1
FEATURES & OPERATING CONTROLS 2
PRECAUTIONS & GENERAL INFORMATION 3
AGENCY LISTING INFORMATION 4
INSTALLATION 4
OPERATION 6
CLEANING INSTRUCTIONS
Standard and GroovedGriddles 8
Chrome-Plated griddles 9
TROUBLESHOOTING SUGGESTIONS 10
EXPLODED VIEWS 11-25
WIRING DIAGRAMS 26-33
PARTS & SERVICE 37
CUSTOMER SERVICE DATA 37
Thank You for purchasing this Wells Bloomeld appliance.
Proper installation, professional operation and consistent maintenance of this appliance will ensure that it
gives you the very best performance and a long, economical service life.
This manual contains the information needed to properly install this appliance, and to use and care for the
appliance in a manner which will ensure its optimum performance.
TABLE OF CONTENTS
SPECIFICATIONS - STANDARD GRIDDLES
INTRODUCTION
1
MODEL VOLTS WATTS
AMPS 3ø AMPS
L1 L2 L3 N 1ø
PG / G136
208/240V 6,750 / 9,000 14.0 / 18.7 28.1 / 32.5 14.0 / 18.7 32.5 / 37.5
480 9,000 9.4 16.2 9.4 18.7
G136EU 380-415V 10,800 15 15 15 0
PG / G196
208V 12,000 28.8 49.9 28.8 57.6
240V 12,000 25 43.3 25 50
480V 12,000 12.5 21.7 12.5 25
G196EU 380-415V 16,100 22.5 22.5 225 0
PG / G236
208V 16,000 48.3 51.3 35 76.9
240V 16,000 41.7 44.4 30.4 66.6
480V 16,000 20.9 22.2 15.5 33.3
G236EU 380-415V 16,000 15.8 31.6 19.2 38.6
PG / G246
208V 21,500 63.4 67.1 45.8 103.3
240V 21,500 55 58.3 39.6 89.5
480V 21,500 27.1 28.9 19.9 43.8
G246EU 380-415V 21,000 20.8 41.7 25 50.6
PG / G606
208V 32,000 48.3 51.3 35 76.9 x 2
240V 32,000 41.7 44.4 30.4 66.6 x 2
480V 32,000 20.9 22 15.1 33.3 x 2
