Specifications

111 p/n 2M-303340 OpManual Built-In Electric Griddles
23
EXPLODED VIEW & PARTS LIST: G606
BUILT-IN ELECTRIC GRIDDLE
MODEL G606 - CABINET & ELECTRICAL
208V, 240V and 480V
HANDLE
2R-38668 (2 reqd)
TRAY FRONT
G7-Z12047 (2 reqd)
WELLS
SHROUD, GREASE
5RAWER WS-51989
(2 reqd)
OUTLET BOX
G7-31997 (2 reqd)
TERMINAL BLOCK
2E-30412 (2 reqd)
BUSHING,
HEYCO 7/8”
2K-31040 (4 reqd)
NUT, HEX ALUMINUM
8-32 x 7/8”
2C-41974 (4 reqd)
THERMO, CONTROL
2T-30257 (8 reqd)
LIGHT, SIGNAL AMBER
208 / 240V 2J-30516
480V M3-WL0113
(8 reqd)
KNOB 2R-30259
(8 reqd)
COVER, OUTLET
BOX G7-32005 (2 ea)
SHIELD, THERMO
2A-31974 (8 reqd)
SPLASHGUARD
RIGHT G7-35782
GRIDDLE PLATE
ASSY WS-55668
SPLASHGUARD ASSY
COMPLETE 5G-20637
SPLASHGUARD, LEFT G7-35783
GREASE DRAWER ASSY
COMPLETE WS-50279 (2 reqd)
SLEEVING, 5/16”
1O-32040 (6” rl) (8 reqd)
2R-30259
SEALANT 5/15” x 132”
1P-33309 (2 pc)
IL1945, Rev. B
