EXPLODED VIEW & PARTS LIST: G236
111 p/n 2M-303340 OpManual Built-In Electric Griddles
BUILT-IN ELECTRIC GRIDDLE
MODEL G236 - HEATING ELEMENTS
208V, 240V and 480V
HEATING ELEMENT
3800W / 208V 2N-30510UL
3800W / 240V 2N-30509UL
3800W / 480V 2N-31428UL
HEATING ELEMENT, PERIMETER
800W / 208/240V 2N-30508UL
800W / 480V 2N-31495UL
(4 ea)
NUT, 10-32
HEX 2C-35313
NUT, 1/4-20 HEX Ni
2C-31253 (36 ea)
CLAMP, ELEM CENTER
DD-32037 (10 ea)
CLAMP, ELEM END
G7-32038 (8 ea)
CLAMP, PERIMETER
ELEMENT RIGHT
G7-32026
CLAMP, PERIMETER
ELEMENT LEFT G7-32027
CLAMP, THERMO
G7-32028 (12 ea)
TUBE, THERMO
2A-31971 (4 ea)
CLIP, INSULATION
G7-33474 (12 ea)
COVER, GREASE
DRAWER G7-31995
INSULATION PAD
2H-36051 (pk 2'x4')
GRIDDLE
SHOWN INVERTED
(ref.)
CLAMP, PERIMETER
ELEMENT CENTER
G7-32025
ELECTRIC GRIDDLE G-236
HEATING ELEMENTS
IL1912 PL111
