PARTS LIST: G136, GG136, PG136
G136 COUNTERTOP ELECTRIC GRIDDLE
Fig No. Part No Description Qty Application
1 WS-20632 SPASHGUARD G136 1 G136
2 G7-35781 SPLASHGUARD LF GRVD 24IN 1 G136
3 G7-34437 SPLASHGUARD RR ASSY G-13 1 G136
4 G7-35780 SPLASHGUARD RT GRVD 24IN 1 G136
5
WS-51476 TOP ASSY G136
1
G136, G136-480V
DD-503703 TOP ASSY G136EU G136-400
M3-304108 G136FGUPL 208/240V 400DE GG136-400FGR
2F-305809 PLATE GRID GRVD GG136EU GG136-400LT
2F-49284A PLATE GRID GRVD GG136EU GG136-400RT
M3-304115 G136 PLATED 208/240V PG136-208V
6 1P-33308 GS #7500 BEAD x 96” 1 G136
7
G7-31997 BOX OUTLET GRIDL ROHS
1
G136, G136-480V
G7-46112 BOX OUTLET G136-400, GG136-400
8
2E-40310 TERM BLOCK 4POLE 75AMP
1
G136-400, GG136-400
WS-50131 TERM BLOCK KIT-3 POLE .85AMP G136
WS-60310 TERM BLOCK 4POLE 75AMP GG136-400FGR
9
2K-300102 STRAIN RELIEF 1NPT .375-1 1 G136-400, GG136-400
2K-31040 BUSHING HEYCO 7/8 OD 2 G136
10 1P-36178 TAPE CORK 1/16 X 2 X 15FT 0.4 G136
11 2C-31053 NUT 8-32 KEPS MS NICKEL
8 G136, G136-480V
9 G136-400
12 2C-31734 SCREW 8-32X2-1/4 SL RDHD 2 G136
13 G7-31989 SHROUD DRWR G13 136 19 19 1 G136
14 2C-33935 SCREW 6ABX5/16 PH PAN SMS
16 G136-480V
22 G136, G136-400
15 G7-WL0002 ASSY - GREASE DRAWER 1 G136
16 G7-Z12047 PANEL FRONT - GREASE DR. 2 G136
17 2R-38668 HANDLE DOOR 1 G136
18 WS-50279 DRAWER GREASSE W/HANDLE 1 G136
19 G7-Z12222 PANEL, CONTROL 1 G136
20
G7-32005 COVER OUTLET BOX GRIDL BI
1
G136, G136-480V
G7-46113 COVER OUTLET BOX G136-400, GG136-400
21 2C-41974 NUT 8-32 HEX 7/8 LONG ALU 2 G136, G136-480V
22
2J-30516 LIGHT SIGNAL AMBER M3938P
2
G136
M3-WL0113 ASSY,PILOT LIGHT AMBER G136-480V, G136-400, GG136-400
23
2R-30259 KNOB CONTROL ASSY
2
G136, G136-480V
2R-46164 KNOB THERMO G136-400, GG136-400
24 2C-31718 SCREW 6-32X3/16 PH RD HD 4 G136
25
2T-30257 THERMO GRIDL 450F SJ-157-
2
G136
2T-46162 THERMO G136-400, GG136-400
26 2A-31974 SHIELD THERMO GRID LS 2 G136
27 1O-32040 SLEEVING GLASS 5/16 I.D. 6 FT G136
28 2H-36051 INSUL FG 1X24X48 4 G136
29
G7-31995 COVER GREASE DRWR G13-6 &
1
G136, G136-480V
G7-46180 CVR GREASE DRWR G13(6) G136-400, GG136-400
30 2C-31253 NUT 1/4-20 FINISHED HEX M 32 G136
