11 WELLS BLOOMFIELD, LLC 10 Sunnen Dr., St. Louis, MO 63143 telephone: 314-678-6314 fax: 314-781-2714 www.wellsbloomfield.
LIMITED WARRANTY STATEMENT Unless otherwise specified, all commercial cooking equipment manufactured by WELLS BLOOMFIELD, LLC is warranted against defects in materials and workmanship for a period of one year from the date of original installation or 18 months from the date of shipment from our factory, whichever comes first, and is for the benefit of the original purchaser only. The prices charged by Wells Bloomfield for its products are based upon the limitations in this warranty.
TABLE OF CONTENTS WARRANTY SPECIFICATIONS FEATURES & OPERATING CONTROLS PRECAUTIONS & GENERAL INFORMATION AGENCY LISTING INFORMATION INSTALLATION OPERATION CLEANING INSTRUCTIONS Standard and GroovedGriddles Chrome-Plated griddles TROUBLESHOOTING SUGGESTIONS EXPLODED VIEWS WIRING DIAGRAMS PARTS & SERVICE CUSTOMER SERVICE DATA xi 1 2 3 4 4 6 8 9 10 11-25 26-33 37 37 INTRODUCTION Thank You for purchasing this Wells Bloomfield appliance.
FEATURES & OPERATING CONTROLS SPLASHGUARD GREASE TROUGH NAMEPLATE HEATING INDICATOR GREASE DRAWER TEMPERATURE CONTROL KNOB Fig. 1 Countertop Griddle Features & Operating Controls G136 Shown - G196, G236, G246 and G606 are Similar Power is applied to the heating elements according to the control knob position and the actual temperature sensed at the thermobulb. When the element is energized the heating indicator will glow. Each section of the griddle is individually controllable.
PRECAUTIONS AND GENERAL INFORMATION DANGER: BURN HAZARD Contact with cooking surface cause severe burns. Always wear protective clothing and avoid contact with griddle surface. WARNING: ELECTRIC SHOCK HAZARD All servicing requiring access to non-insulated components must be performed by qualified service personnel. DO NOT open any access panel that requires the use of tools. Failure to heed this warning may result in severe electric shock.
AGENCY LISTING INFORMATION This appliance conforms to NSF Standard 4 for sanitation only if installed in accordance with the supplied Installation Instructions. This appliance is Underwriters Laboratory recognized ( ). Since this appliance is only a single component of a complete installation, the finished installation of this unit requires additional evaluations to Underwriters Laboratory standards.
INSTALLATION (continued) WARNING: Electric Shock hazard All servicing requiring access to non-insulated electrical components must be performed by a factory authorized technician. DO NOT open any access panel which requires the use of tools. Failure to follow this warning can result in severe electrical shock. ELECTRICAL INSTALLATION CAUTION: Refer to the nameplate. Verify the electrical service power. Voltage and phase must match the nameplate specifications.
OPERATION CAUTION: Hot surface Exposed surfaces can be very hot and may cause severe burns on contact. PREPARING THE GRIDDLE SURFACE SEASONING STANDARD AND GROOVED GRIDDLES As manufactured, the steel surface of your Wells griddle has microscopic pores. It is important to fill these pores with oil in order to provide a hard, non-stick cooking surface. a. Preheat griddle surface to 375ºF (191ºC). b. Spread a light film of cooking oil over entire griddle surface. c.
OPERATION (continued) NOTE: NOTE: Separate sections of griddle may be set to different temperatures. This will allow a variety of products to be prepared at the same time, and will allow prepared product to be held at serving temperature after cooking. The times and temperatures in this chart are suggestions only. For best results, different temperatures should be set from coolest to hottest sequentially across the width of the griddle. (Heat will migrate over the entire griddle surface.
CLEANING INSTRUCTIONS - STANDARD AND GROOVED GRIDDLES PREPARATION Set temperature control to 220ºF. Allow griddle temperature to drop to 220ºF before proceeding. FREQUENCY Daily TOOLS Griddle Brick or Pumice Stone, Fiber Brush Plastic Scouring Pad, Plastic Scraper Contoured Scraper (grooved griddle) Mild Detergent, Non-Abrasive Cleanser Clean Soft Cloth / Sponge Burn Hazard Griddle will be hot during portions of this cleaning procedure. Always heatprotective gloves and apron.
CLEANING INSTRUCTIONS - CHROME PLATED GRIDDLES PREPARATION Set temperature control to 220ºF. Allow griddle temperature to drop to 220ºF before proceeding. FREQUENCY Daily TOOLS 4” Razor-Style Scraper, Soft Bristle Brush Mild Detergent, Non-Abrasive Cleanser Clean Soft Cloth / Sponge Pour a small amount of water on the griddle surface and let it “sizzle”.
TROUBLESHOOTING SUGGESTIONS Griddle will not heat One section does not heat Griddle drips grease POSSIBLE PROBLEM SUGGESTED REMEDY Circuit breaker off or tripped Reset circuit breaker Temperature control knobs not set to desired temperature Set to desired temperature Damaged internal component Contact Wells Authorized Service Agency for repairs Grease drawer full or not installed Damaged internal component Empty grease drawer.
EXPLODED VIEW: G136 Cabinet & Electrical BUILT-IN ELECTRIC GRIDDLE MODEL G136 - CABINET & ELECTRICAL 208/240V and 480V 2 1 3 4 5 6 27 26 7 25 8 24 9 23 22 21 10 20 111 p/n 2M-303340 OpManual Built-In Electric Griddles 19 11 12 18 17 13 16 15 14 KNOB 2R-50259 MODEL G136, GG136 & PG136 CABINET & ELECTRICAL 208/240V, 380/415V and 480V 11 IL1909, Rev.
EXPLODED VIEW: G136 Heating Elements BUILT-IN ELECTRIC GRIDDLE MODEL G136 - HEATING ELEMENTS 208/240V and 480V 28 29 30 31 38 32 37 33 36 35 T ON FR GRIDDLE (REF.) shown inverted MODEL G136, GG136 & PG136 HEATING ELEMENTS 208/240V, 380/415V and 480V 12 IL1908, Rev.
PARTS LIST: G136, GG136, PG136 Fig No.
PARTS LIST: G136, GG136, PG136 36 37 Part No G7-32028 G7-46178 2A-31972 G7-31968 G7-46169 2E-32054 2N-30496UL 2N-45922UL 2N-48904UL 2C-35313 G7-31969 38 G7-33474 NI NI G7-32089 G7-34786 NI NI 2M-46211 2M-48929 31 32 33 34 35 G136 COUNTERTOP ELECTRIC GRIDDLE continued Description Qty Application 4 G136, G136-480V CLAMP THERMO BULB GRIDL 2 G136-400, GG136-400 TUBE THERMO 18 LINE GRID 2 G136 CLAMP ELEM CTR SMALL GRID 6 G136, G136-480V CLAMP ELEM EU ROHS 2 G136-400, GG136-400 JUMPER, ELEMENT MEDIUM 4
PARTS LIST: G136 BUILT-IN ELECTRIC GRIDDLE MODEL G196 - HEATING ELEMENTS 208V, 240V, 380-415V and 480V 11 10 9 8 7 1 2 3 5 4 111 p/n 2M-303340 OpManual Built-In Electric Griddles 6 GRIDDLE SHOWN INVERTED (ref.
EXPLODED VIEW: G196 BUILT-IN ELECTRIC GRIDDLE MODEL G196 - CABINET & ELECTRICAL 208V, 240V, 380-415V and 480V 13 14 12 15 16 17 36 35 18 19 34 20 33 21 32 30 29 28 22 27 23 WE LL S 24 26 25 IL1911 Rev.
EXPLODED VIEW: G196 G196 COUNTERTOP ELECTRIC GRIDDLE Fig No.
EXPLODED VIEW & PARTS LIST: G236 BUILT-IN ELECTRIC GRIDDLE MODEL G236 - HEATING ELEMENTS 208V, 240V and 480V INSULATION PAD 2H-36051 (pk 2'x4') COVER, GREASE DRAWER G7-31995 CLIP, INSULATION G7-33474 (12 ea) CLAMP, THERMO G7-32028 (12 ea) CLAMP, PERIMETER ELEMENT RIGHT G7-32026 TUBE, THERMO 2A-31971 (4 ea) NUT, 1/4-20 HEX Ni 2C-31253 (36 ea) CLAMP, ELEM END G7-32038 (8 ea) NUT, 10-32 HEX 2C-35313 CLAMP, PERIMETER ELEMENT CENTER G7-32025 HEATING ELEMENT (4 ea) 3800W / 208V 2N-30510UL 3800W / 240V 2N-
EXPLODED VIEW & PARTS LIST: G236 BUILT-IN ELECTRIC GRIDDLE MODEL G236 - CABINET & ELECTRICAL 208V, 240V and 480V SPLASH GUARD ASSY, G-236 COMPLETE 5G-20635 SPLASHGUARD, LEFT G7-35783 SPLASHGUARD, RIGHT G7-35782 GRIDDLE PLATE ASSEMBLY (SMOOTH) WS-51490 SEALANT 5/15” x 132” 1P-33309 SLEEVING, 5/16” 1O-32040 (6” rl) (4 reqd) SHIELD, THERMO 2A-31974 (4 reqd) LIGHT, SIGNAL AMBER 208 / 240 V 2J-30516 480V M3-WL0113 (4 reqd) THERMO, CONTROL 2T-30257 (4 ea) OUTLET BOX G7-31997 TERMINAL BLOCK 2E-30412 NUT, HE
EXPLODED VIEW & PARTS LIST: G246 BUILT-IN ELECTRIC GRIDDLE MODEL PG246, G246 - HEATING ELEMENTS 208V, 240V and 480V INSULATION PAD 2H-36051 (8 sf) (pk 2'x4') COVER, GREASE DRAWER G7-31995 CLIP, INSULATION G7-33474 (16 ea) NUT, 1/4-20 HEX 2C-31253 (64 ea) CLAMP, THERMO BULB GRIDDLE G7-32028(12 ea) TUBE, THERMO 24" 2A-31971 (4 ea) NUT, 10-32 HEX 2C-35313 (36 ea) JUMPER, SHORT 2E-32054 (8 ea) CLAMP, ELEM LF G7-32027 CLAMP, ELEM END G7-31969 (16 ea) CLAMP, ELEM RT G7-32027 ELEMENT (8ea) 208V 2500W 2N-
EXPLODED VIEW & PARTS LIST: G246 BUILT-IN ELECTRIC GRIDDLE MODEL PG246, G246 - CABINET & ELECTRICAL 208V, 240V and 480V SPLASHGUARD, LEFT G7-35783 SPLASH GUARD ASSY, G-24 COMPLETE 5G-20636 SPLASHGUARD, RIGHT G7-35782 DD-35667 GRIDDLE PLATE ASSY DD-52010, G246 DD-41000, PG246 SEALANT 5/15” x 160” 1P-33310 SLEEVING, 5/16” 1O-32040 (6” rl) (4 reqd) SHIELD, THERMO 2A-31974 (4 reqd) THERMO, CONTROL 2T-30257 (4 ea) LIGHT, SIGNAL AMBER 208 / 240V 2J-30516 480V M3-WL0113 (4 reqd) TERMINAL BLOCK 2E-31276 SCR
EXPLODED VIEW & PARTS LIST: G606 BUILT-IN ELECTRIC GRIDDLE MODEL G606 - HEATING ELEMENTS 208V, 240V and 480V COVER, GREASE DRAWER (2 ea) G7-31995 INSULATION PAD 2H-36051 (12 sf) (pk 2'x4') CLIP, INSULATION G7-33474 (24 ea) (pk12) CLAMP, THERMO G7-32028 (24 ea) CLAMP, PERIMETER ELEMENT RIGHT (2 ea) G7-32026 TUBE, THERMO 2A-31971 (8 ea) NUT, 1/4-20 HEX Ni 2C-31253 (72 ea) CLAMP, ELEM END G7-32038 (16 ea) NUT, 10-32 HEX 2C-35313 (40 ea) CLAMP, ELEM CENTER DD-52037 (20 ea) NOTE: ONLY 1/2 OF GRIDDLE IS S
EXPLODED VIEW & PARTS LIST: G606 BUILT-IN ELECTRIC GRIDDLE MODEL G606 - CABINET & ELECTRICAL 208V, 240V and 480V SPLASHGUARD, LEFT G7-35783 SPLASHGUARD RIGHT G7-35782 SPLASHGUARD ASSY COMPLETE 5G-20637 GRIDDLE PLATE ASSY WS-55668 SLEEVING, 5/16” 1O-32040 (6” rl) (8 reqd) THERMO, CONTROL 2T-30257 (8 reqd) LIGHT, SIGNAL AMBER 208 / 240V 2J-30516 480V M3-WL0113 (8 reqd) SHIELD, THERMO 2A-31974 (8 reqd) KNOB 2R-30259 (8 reqd) SEALANT 5/15” x 132” 1P-33309 (2 pc) SHROUD, GREASE 5RAWER WS-51989 (2 reqd)
EXPLODED VIEW & PARTS LIST: JG246UL COUNTERTOP ELECTRIC TEPPAN-YAKI GRIDDLE MODEL JG246UL - CABINET & HEATING ELEMENTS 208/240V & 480V 2C-33935 (22 ea) 57047 (4 sf) (pk 2'x4') 2I-Z12311 (2 ea) 2K-34136 (2 ea) 2C-31253 (18 ea) I7-41830 (2 ea) G7-33474 (6 ea) 2N-41738UL, 208/240V (2 ea) 2N-304817UL, 480V (2 ea) GRIDDLE (ref) shown inverted 2C-35736 IL1946, Rev.
EXPLODED VIEW & PARTS LIST: JG246UL COUNTERTOP ELECTRIC TEPPAN-YAKI GRIDDLE MODEL JG-246UL - CONTROL PANEL & ELECTRICAL 208/240V & 480V 2K-34136X (2 ea) 1O-32040 (3') 2I-Z12311 (2 ea) 2C-35736 1P-36178 (1/16"x2"x12") WS-50131 2C-41974 (2 ea) 2C-33935 (22 ea) WS-50385 WS-50385 E-Safe Relay 2E-306967B 2C-31053 ON F OF 5 250 0 0 350 300 Contactor, 3P, 40A, JG246U-480 2E-37780 40 S LL E W 2R-300356 2E-33192 NEW-STYLE GRIDDLE 2C-34284 (2 ea) OLD-STYLE GRIDDLE 111 p/n 2M-303340 OpManual Bui
WIRING DIAGRAM FIELD CONVERSION FROM 3-PHASE TO SINGLE-PHASE CONTROL KNOB CONFIGURATION For all models, control knob p/n 50259 is marked in degrees Fahrenheit from 200ºF to 450ºF. When the thermostat is OFF, the flat of the control shaft is positioned on the bottom. 26 111 p/n 2M-303340 OpManual Built-In Electric Griddles Griddles are shipped from the factory wired for 3-phase power, 208 volt and 240 volt griddles are field convertible to single-phase.
WIRING DIAGRAM JG246UL TEPPAN GRIDDLE FIELD CONVERSION FROM 3-PHASE TO SINGLE-PHASE Griddles are shipped from the factory wired for 3-phase power, Teppan Griddles are field convertible to single-phase. CONTROL KNOB CONFIGURATION 111 p/n 2M-303340 OpManual Built-In Electric Griddles For Teppan Griddles, control knob p/n 500536 is marked in degrees Fahrenheit from 150ºF to 550ºF. When the thermostat is OFF, the flat of the control shaft is positioned on the top.
111 p/n 2M-303340 OpManual Built-In Electric Griddles WIRING DIAGRAM 28
111 p/n 2M-303340 OpManual Built-In Electric Griddles WIRING DIAGRAM: G196 29
111 p/n 2M-303340 OpManual Built-In Electric Griddles WIRING DIAGRAM: G236 30
111 p/n 2M-303340 OpManual Built-In Electric Griddles WIRING DIAGRAM: G246 31
111 p/n 2M-303340 OpManual Built-In Electric Griddles WIRING DIAGRAM: G606 32
111 p/n 2M-303340 OpManual Built-In Electric Griddles WIRING DIAGRAM: JG246UL 33
111 p/n 2M-303340 OpManual Built-In Electric Griddles NOTES 34
111 p/n 2M-303340 OpManual Built-In Electric Griddles NOTES 35
111 p/n 2M-303340 OpManual Built-In Electric Griddles NOTES 36
PARTS & SERVICE DESCRIPTION PART NO. legs, 4” , METAL set of 4 WS-20563 splashguard, fits G-136 WS-20632 splashguard, fits G-196 WS-20634 splashguard, fits G-236 WS-20635 splashguard, fits G-246 WS-20636 splashguard, fits G-606 WS-20637 SCRAPER, GROOVED GRIDDLE WS-20651 IMPORTANT: Use only factory authorized service parts and replacement filters.
