Instruction manual

6.9.1 Set Digital Zoom mode
C/SIDbyte
4
0x6E0xA
A
0xC5
byte
4
dum dum C/Sdumdum0x6E0xAA0xC5
① byte4 = 0x00 ; Digital Zoom mode OFF
② byte4 = 0x01 ; Digital Zoom mode ON
6.9.2 Read Digital Zoom Power
C/SID0x000x8F0xA
A
0xC5
0x00 byte5 dum C/Sdumdum0x8F0xAA0xC5
① byte5 = 0x02 ; “x2”.
② byte5 = 0x03 ; “x3”
③ byte5 = 0x04 ; “x4”
④ byte5 = 0x05 ; “x5”
⑤ byte5 = 0x06 ; “x6”
⑥ byte5 = 0x07 ; “x7”
⑦ byte5 = 0x08 ; “x8”
⑧ It is v alid only when Digital Zoom mode is ON.
6.9 ZOOM
6.9.3 Set Digital Zoom Power
C/SIDdumbyte30x520xC5
dum dum dum C/Sdumdumbyte
3
0x520xC5
① byte5 is Digital Zoom Power (Ref er to 6.9.3)
② It is v alid only when Digital Zoom mode is ON.
③ In case that Digital Zoom Power is “x2”, End Zoom is “x23 ~ x46”.
① byte4 = 0x00 ; Backlight mode OFF
② byte4 = 0x01 ; Backlight mode ON
③ Auto is prior to ON/OFF in Backlight mode.
6.10.2 Set Backlight mode ( It is sav ed on EEPROM. )
6.10 Backlight Mode
6.10.1 Set Backlight mode
C/SIDbyte
4
0x700xA
A
0xC5
byte
4
dum dum C/Sdumdum0x700xAA0xC5
C/SIDdumbyte
3
0xA
A
0xC5
dum dum dum C/Sdumdumbyte
3
0xAA0xC5
① byte3 = 0x56 ; Backlight mode ON
② byte3 = 0x57 ; Backlight mode OFF
6.10.3 Set Auto Backlight mode ( It is not sav ed on EEPROM. )
C/SIDbyte40x6D0xAA0xC5
byte
4
dum dum C/Sdumdum0x6D0xAA0xC5
① byte4 = 0x01 ; Auto Backlight mode ON
② byte4 = 0x00 ; Auto Backlight mode OFF
6.10.4 Read Auto Backlight Area
① byte5 is current Auto Backlight area.
C/SIDdumdum0x840xC5
dum byte5 dum C/Sdumdumdum0x840xC5
0: Area 1 OFF1: Area 1 ONBit0
0: Area 2 OFF1: Area 2 ONBit1
0: Area 3 OFF1: Area 3 ONBit2
0: Area 4 OFF1: Area 4 ONBit3
0: Area 5 OFF1: Area 5 ONBit4
N/CBit5,6,7
< Table 6-2. Auto BLC area bit >
- 21 -
