6.5.4 Adjust Weighting v alue of Auto Exposure detection windows
C/SIDbyte
4
0x6C0xA
A
0xC5
byte4 dum dum C/Sdumdum0x6C0xAA0xC5
① byte4 is weighting v alue of AE detection windows to adjust Camera.
(upper 4bit ; weighting v alue f or WIND1.
lower 4bit ; weighting v alue f or WIND2. Ref er to 6.5.3)
6.5.5 Read AGC lev el
C/SID0x000x8C0xA
A
0xC5
0x00 byte5 dum C/Sdumdum0x8C0xAA0xC5
① byte5 is the current AGC lev el of Camera.
6.5.6 Adjust AGC lev el
C/SIDbyte
4
0x7D0xA
A
0xC5
byte
4
dum dum C/Sdumdum0x7D0xAA0xC5
① byte4 = 0x33 ~ 0xE8 ; AGC lev el of the Camera.
(only in AGC FIX or MANUAL Exposure mode : Ref er to 6.5.1).
C/SIDdumbyte
3
0xA
A
0xC5
dum dum dum C/Sdumdumbyte
3
0xAA0xC5
① byte3 = 0x66 ; AUTO Iris mode
② byte3 = 0x67 ; MANUAL Iris mode
① byte4 is IRIS data of Camera lens
(only in IRIS FIX or MANUAL Exposure mode : Ref er to 6.5.1 ).
② The range of IRIS data is 0x33 ~ 0xCD.
6.6.3 Adjust IRIS data
C/SIDbyte40x7C0xAA0xC5
byte4 dum dum C/Sdumdum0x7C0xAA0xC5
6.6 IRIS mode
6.6.1 Set AUTO / MANUAL Iris mode ( It is not sav ed. )
C/SIDbyte
4
0x5D0xA
A
0xC5
byte
4
dum dum C/Sdumdum0x5D0xAA0xC5
① byte4 = 0x00 ; High mode - Reaction is f ast.
② byte4 = 0x01 ; Low mode - Reaction is stable.
6.5.7 Set Auto Exposure Sensitiv ity Mode
1/100000x1B1/9000x0D
1/60000x1A1/8000x0C
1/40000x191/7000x0B
1/35000x181/6000x0A
1/30000x171/5000x09
1/25000x161/4500x08
1/20000x151/4000x07
1/18000x141/3500x06
1/16000x131/3000x05
1/15000x121/2500x04
1/13000x111/2000x03
1/12000x101/1500x02
1/11000x0F1/1250x01
1/10000x0E1/60 1/500x00
NTSC/PAL shutter speedbyte4NTSC/PAL shutter speedbyte4
< Table 6-1. Shutter Speed >
① byte5 is the current IRIS data of Camera lens.
C/SIDdum0x8B0xA
A
0xC5
dum byte5 dum C/Sdumdum0x8B0xAA0xC5
6.6.2 Read IRIS data
