6.3 EEPROM
6.3.1 Read EEPROM data (f ront 2K by te out of 4K by te)
C/SIDdumbyte
3
0xF00xC5
dum byte5 dum C/Sdumdumbyte
3
0xF00xC5
① byte3 is EEPROM address to read ( 0x00 ~ 0xFF )
② ID : Camera’s ID ( Ref er 6.2.1)
③ byte5 is EEPROM data of EEPROM address
6.3.2 Write EEPROM data ( f ront 2K byte out of 4K by te )
① byte3 is EEPROM address to write ( 0x00 ~ 0xFF )
② byte4 is data to write on EEPROM address
6.4 White Balance Mode
6.4.1 Read WB mode
C/SIDbyte
4
byte
3
0x0F0xC5
byte
4
dum dum C/Sdumdumbyte
3
0x0F0xC5
① byte5 = 0x00 ; ATW mode
② byte5 = 0x02 ; INDOOR WB mode
③ byte5 = 0x03 ; OUTDOOR WB mode
④ byte5 = 0x04 ; MANUAL WB mode
⑤ byte5 = 0x05 ; AWC mode
6.4.2 Set WB mode
C/SIDdum0x830xA
A
0xC5
dum byte5 dum C/Sdumdum0x830xAA0xC5
① byte4 = 0x00 ; ATW mode
② byte4 = 0x02 ; INDOOR WB mode
③ byte4 = 0x03 ; OUTDOOR WB mode
④ byte4 = 0x04 ; MANUAL WB mode
⑤ byte4 = 0x05 ; AWC mode
C/SIDbyte
4
0x650xA
A
0xC5
byte
4
dum dum C/Sdumdum0x650xAA0xC5
① byte4 = 0x00 ; AWC mode “Lock”
② byte4 = 0x01 ; AWC mode “Push”
6.4.4 Read HUE data at the MANUAL WB mode
6.4.3 Set AWC mode
C/SIDbyte
4
0x780xA
A
0xC5
byte
4
dum dum C/Sdumdum0x780xAA0xC5
① byte5 is the current HUE data at MANUAL WB mode (0x00 ~ 0x63).
6.4.5 Adjust HUE data at the MANUAL WB mode
C/SIDdum0x870xA
A
0xC5
dum byte5 dum C/Sdumdum0x870xAA0xC5
C/SIDbyte
4
0x770xA
A
0xC5
byte4 dum dum C/Sdumdum0x770xAA0xC5
① byte4 = 0x00 ~ 0x63 ; 0 ~ 99(decimal) is HUE data at MANUAL WB mode
6.4.6 Set ATW / MANUAL WB mode
① byte3 = 0x68 ; ATW mode
② byte3 = 0x69 ; MANUAL WB mode
③ It is not sav ed.
C/SIDdumbyte30xAA0xC5
dum dum dum C/Sdumdumbyte
3
0xAA0xC5
