Instruction manual

Set Start Zoom ratio
: Set boundary v alue of WIDE zooming.
START ZOOM x 1 ~ x 22 ( in optical zoom region )
Set End Zoom ratio
: Set boundary v alue of TELE zooming. It can be set up to 184 x including
electronic zoom. ( in case the digital zoom limit is 8 times ) Since Start Zoom
and End Zoom ratio are set, simultaneously Camera mov es to setting zoom
times. So it can be enable to adjust in mov ing to desired position.
END ZOOM x 23 ~ x 184 ( in digital zoom region )
☞ caution
1. End Zoom value must be lager than Start Zoom ratio.
Camera ID Display Mode
: Camera ID is indicating number assigned each Camera in case of
controlling many Cameras. It is f rom 0 to 255. But in case of 0, that is not
display ed on screen. It is alway s display ed ev en though whole Operating
OSD is disappeared on the screen. But it is possible to make non display
and to choose display position (BOTTOM RIGHT, TOP RIGHT, TOP LEFT)
by RS-232C communication.
ID DISPLAY 0 ~ 255
☞ caution
1. I n cas e of Camera ID FIX model, it cannot be s elected.
Special Menu (Option)
: Use f or Entering Special Menu.
<<SPECIAL MENU>>
AF SENS.
ZOOM SPEED
O.S. AF TIME
MIN DIST
SHUTTER
BAUD RATE
AE SENS.
BLC LEVEL
OSD DISP.
RETURN MENU
HIGH
HIGH
5sec
50cm
NORMAL
9600bps
HIGH
24
ALL
AF SENS. Control
: High : Reaction of Auto Focus is f ast. It can be used when it shoot
objects mov ing f ast.
Low : Auto Focus is more stable. In f ast mov ing scene, AF doesn’t work
ev en though the scene is changed. It is f or stabilizing the scene.
AF SENS. HIGH → LOW → ….
ZOOM Speed Control
: Set the zoom speed.
ZOOM SPEED HIGH → MEDIUM → LOW
OneShot AF TIME control
: Set the Oneshot taking time in Focus mode.
O.S. AF TIME 1sec ~ 9 sec
Set Minimum Distance
: Set the minimum distance which can be f ocalized.
MIN DIST 1cm → 10cm → 50cm → 1m → 3m → 10m → infinity
Shutter Speed Control
: Set the Shutter Speed. (Ref er to. 17page Table 6-1)
At this time, Exposure mode becomes Shutter Fix mode.
SHUTTER NORMAL→ 1/125 → … → 1/10000 → NORMAL
Set BAUD RATE
: Set Baudrate to communicate by RS232C, RS485, RS232TTL.
BAUD RATE 9600bps → 1200bps → 2400bps → 4800bps →
19200bps → 38400bps → 76800bps → 115kbps
AE SENS. Control
AE SENS. HIGH → LOW
Set BLC Level
BLC LEVEL 24 ( 0 ~ 80 variable )
Set Operating OSD display
OSD DISP ALL → NONE → TOP → BOTTOM → ALL → ...
ALL : Display all operating OSD ( Focus mode& key action
status
, Zoom position , ID
Display )
NONE : Clear all OSD except MENU page
TOP : Display top position OSD only ( Focus mode , key action
status)
BOTTOM : Display bottom position OSD only ( Zoom position , ID )
5.7 SPECIAL MENU f unctions
< Fig 5-6. SPECIAL MENU >
- 13 -
