OPERATION MANUAL Built-in x 23 ZOOM AUTO FOCUS COLOR CAM ERA WDAC-2308X WDN-2308X READ AND KEEP THIS OPERATION MANUAL WELDEX CORPORATION
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. PREFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Indicate a potentially hazardous situation which if not avoided, may result in minor or moderate injury. It may also be used to alert against unsafe practices. Warning: This equipment generates and uses radio frequency energy and if not installed and used properly, I.e.
CAUTION FOR SAFE OPERATION 1. Wate r and M oisture To prevent fire or shock hazard, do not expose this camera to rain or moisture. 8. Whe n operation is incorrect or a m alfunction is observed While operating, if any abnormal condition (strange sound, smell or smoke) or a malfunction (no pictures, etc.) is observed, stop using the camera immediately, turn the 2. Servicing Do not attempt to disassemble or repair by yourself. You may be exposed to dangerous voltage or other hazards.
CONTENTS 1. Features -------------------------------------------------------------- 4 2. Names & Functions ---------------------------------------------- 5 3. Installation----------------------------------------------------------- 6 4. Camera Control Methods------------------------------------------ 7 5. On Screen Display -------------------------------------------------- 9 6. Communication Protocol------------------------------------------ 14 7.
1. Features Idea l Digita l Video Camera for Securi ty AI / Fuzzy Control Circuit with DSP The WDAC-2308X is a compact camera that of f ers easy sy stem integration.Coming with the built-in zoom lens,the user can monitor the scene f rom v ariable angle without the extra lens. And,with the D.S.P. technology ,such intelligent controls as auto iris , auto back light compensation and auto white balance are possible to realize clear detailed picture.
2. Names & Functions FAR(-) BUTTON S-VIDEO OUTPUT This is the output terminal for separate Y/C signal . TELE(UP) BUTTON NEAR(+) BUTTON SVIDEO VIDEO MENU DISPLAY BUTTON POWER WIDE(DOWN) BUTTON CONT VIDEO OUTPUT This is the output terminal for composite video signal . POWER INPUT TERMINAL DC 12V input ( Please use a specified DC adaptor) ( Be careful its polarity ) CAMERA CONTROL CONNECTOR POWER ON LAMP This is the 14 pin connector for external In power ON state , this LED is ON . camera controls .
3. Installation 3.1 Check all accessories with enclosed package . -WDAC-2308X SET - 14 PIN CONNECTION CABLE - OPERATION MANUAL ( ENGLISH EDITION) WDAC-2308X 14 PIN CONNECTION CABLE OPERATION MANUAL 14P CABLE DESCRIPTION ; 1. 3. 5. 7. 9. 11. 13 KEY1 ( RED ) ZOOM ( GREEN ) MENU ( WHITE ) GND ( BLACK ) R+/NC ( BROWN ) T+/TD ( VIOLET ) EXT_VD ( WHITE ) 2. 4. 6. 8. 10. 12. 14.
4. Camera Control Methods 4.1 Remote Control using for Hard wired connection ( Connector pin 3,4,5,6 ) Controller TELE (-) WIDE(+) 14P Cable NEAR(+) FAR (-) MENU ON 4.
4.
5. On Screen Display FUNCTION ① , Focus Mode ② Back Light ③ Flickerless ④ Shutter Speed 5.1 How to display Operating OSD a. Pressing the MENU key sof tly conf irm current Operating OSD. It is disappeared about f iv e seconds later if there are no other key actions. b. When it zoom in or out pressing TELE(up) or WIDE(down) key , ⑤ whole Operating OSD is display ed and then disappeared.
5.2 Display SETUP MENU a. Press MENU key abov e 2 seconds so that SETUP MENU 1 is display ed on the screen. b. Select item of SETUP MENU using TELE(up) / WIDE(down) key . c. NEAR(+) / FAR(-) key is used to increase / decrease data of selected item. >>SETUP M ENU 1<< . . . . . . NEXT M ENU 5.3 Mov e between SETUP MENU 1 and SETUP MENU 2 a. In order to change f rom SETUP MENU1 to SETUP MENU 2, select NEXT MENU using TELE / WIDE key , and press NEAR / FAR key . b.
ⅱ) Set BLC area in Backlight Auto mode ⅰ) Set AUTO BLC mode >> SETMENU 1 << BACKLIGHT AUTO . . . . . 1 1 5 5 1 ? 5 NEXT MENU Press MENU key , then display ed backlight area that can be modif y ing ( Ref er to B ) Press NEAR(+) or FAR(-) key abov e 2 sec, then Backlight mode becomes Auto. If y ou want to change BLC area , Mov e to desirable area using TELE(up)/WIDE(down) key . The selected area becomes blinking. 1 Press MENU key , then display ed SETUP MENU1 again.
④ Mirror Mode : Mode ON is Mirror mode, Mode OFF is general screen state. MIRROR OFF → ON → . . . . 5.6 SETUP MENU 2 f unctions ⑤ Sharpness Control : Use to change the contour of scene . SHARPNESS 0 ~ 15 ⑥ Brightness Control : Adjust open and close lev el of iris in AI mode. The normal v alue is 48(50). The smaller brightness v alue is, the darker it is, because iris is closed more. On the contrary the bigger brightness v alue is, the brighter it is, because iris is opened more.
Set Start Zoom ratio : Set boundary v alue of WIDE zooming. START ZOOM x 1 ~ x 22 ( in optical zoom region ) Set End Zoom ratio : Set boundary v alue of TELE zooming. It can be set up to 184 x including electronic zoom. ( in case the digital zoom limit is 8 times ) Since Start Zoom and End Zoom ratio are set, simultaneously Camera mov es to setting zoom times. So it can be enable to adjust in mov ing to desired position. END ZOOM x 23 ~ x 184 ( in digital zoom region ) ☞ caution 1.
6. Communication Protocol ( RS-232C,RS-422) 6.1 Serial Communication 6.1.1 Communication Format A) Data length : 1by te (8bit) B) Start bit / Stop bit : 1bit C) Parity bit : none D) Baud rate : 9600bps 6.2 Camera ID 6.2.1 Read Camera ID byte2 byte3 byte4 0xC C dum dum dum C/S 0xC 5 0xC C dum dum byte 5 dum dum dum C/S ① 0xC5 means this protocol is to communicate between PC and CAMERA. 6.1.2 PC send 6by tes to Camera. byte1 0xC5 byte5 ② To communicate camera, read Camera ID f irst.
6.3 EEPROM 6.3.1 Read EEPROM data (f ront 2K by te out of 4K by te) 0xC5 0xF0 byte 3 dum ID 0xC5 0xF0 byte 3 dum byte5 6.4.3 Set AWC mode dum dum dum byte 3 byte 4 ID 0xC5 0x0F byte 3 byte 4 dum 0xC5 0xAA 0x78 byte 4 dum dum dum dum C/S 0xC5 0xA A 0x87 dum ID C/S dum dum dum 0xC5 0xAA 0x87 dum byte5 dum dum dum C/S C/S ① byte5 is the current HUE data at MANUAL WB mode (0x00 ~ 0x63). 0xC5 0xA A 0x83 dum ID 0xC5 0xAA 0x83 dum byte5 6.4.
6.5 Exposure mode 6.5.1 Read Exposure mode 6.4.7 Read RED data at ATW WB mode 0xC5 0xA A 0x85 dum ID 0xC5 0xAA 0x85 dum byte5 0xC5 C/S dum dum dum 0xC5 C/S ① byte5 is the current RED data at ATW WB mode.
6.6.2 Read IRIS data 6.5.4 Adjust Weighting v alue of Auto Exposure detection windows 0xC5 0xA A 0x6C byte 4 ID 0xC5 0xAA 0x6C byte4 dum C/S dum dum dum C/S 0xC5 0xA A 0x8B dum 0xC5 0xAA 0x8B dum ID C/S byte5 dum dum dum C/S dum dum C/S ① byte5 is the current IRIS data of Camera lens. ① byte4 is weighting v alue of AE detection windows to adjust Camera. (upper 4bit ; weighting v alue f or WIND1. lower 4bit ; weighting v alue f or WIND2. Ref er to 6.5.3) 6.6.
6.6.4 Read Shutter Speed ( Ref er to. Table 6-1) 0xC5 0xAA 0x8A 0x00 ID C/S 0xC5 0xAA 0x8A 0x00 byte5 dum 6.7.4 Focus Manual Adjust (only in Manual Focus mode) dum dum C/S 0xC5 0xA A byte 3 dum ID 0xC5 0xAA byte 3 dum dum C/S dum dum dum C/S dum dum C/S dum dum C/S dum dum C/S ① byte3 = 0x5A ; FOCUS as FAR ② byte3 = 0X5B ; FOCUS as NEAR ③ byte3 = 0X5C ; FOCUS STOP ① byte5 is the current counter data to control Shutter Speed 6.6.5 Adjust Shutter Speed 6.7.
6.8 PRESET 6.8.1 Read Lens Zoom Position & Digital Zoom data 0xC5 0x36 dum dum ID C/S 0xC5 0x36 dum dum byte5 byte 6 6.8.3.2 Read Zoom Position, Focus Position , D.zoom Data on EEPROM ( rear 2K by te out of 4K by te) byte 7 dum 0xC5 0xF1 byte 3 dum ID C/S 0xC5 0xF1 byte 3 dum byte5 dum C/S ① byte5 = upper by te of Lens Zoom Position. dum dum C/S ① by te3 is address to read preset data. ② byte6 = lower by te of Lens Zoom Position. ② by te5 is partial data of preset data.
6.8.3.6 Quick Auto Zoom Tracking mov ing Control 0xC5 0x7E byte 3 dum ID 0xC5 0x7E byte 3 dum dum 6.8.4.3 Store Lens D.zoom Position C/S dum dum dum C/S ④ At this time lens mov e to the position with zoom tracking quickly . 6.8.3.7 Read Zoom tracking PRESET status dum ID C/S 0xC5 0x7F dum dum byte5 dum byte4 ID C/S 0xC5 0x4B byte 3 byte 4 dum dum dum dum C/S dum dum C/S dum C/S 6.8.4.
6.9 ZOOM 6.10 Backlight Mode 6.10.1 Set Backlight mode 6.9.1 Set Digital Zoom mode 0xC5 0xA A 0x6E byte 4 ID 0xC5 0xAA 0x6E byte 4 dum C/S dum dum dum C/S 0xC5 0xA A 0x70 byte 4 ID C/S 0xC5 0xAA 0x70 byte 4 dum dum dum dum C/S dum C/S ① byte4 = 0x00 ; Backlight mode OFF ① byte4 = 0x00 ; Digital Zoom mode OFF ② byte4 = 0x01 ; Backlight mode ON ② byte4 = 0x01 ; Digital Zoom mode ON ③ Auto is prior to ON/OFF in Backlight mode. 6.10.
6.10.5 Set Auto Backlight Area 0xC5 0x85 byte 3 dum ID 0xC5 0x85 byte 3 dum dum 6.11 On Screen Display 6.11.1 Read MENU OSD display ON / OFF C/S dum dum dum 0xC5 0xAA 0x8D 0x00 ID C/S 0xC5 0xAA 0x8D 0x00 byte5 dum C/S ① byte3 is Auto Backlight area to set. (Ref er to. 6.10.4) dum dum C/S dum dum C/S ① byte5 = 0x00 ; MENU OSD is not display ed. ② byte5 = 0x01 ; MENU OSD is display ed. Area 1 6.11.
6.11.5 Set Operating OSD Display mode 0xC5 0xC5 0xA A 0xAA 0x64 0x64 byte 4 byte 4 ID C/S dum dum 6.13.2 Adjust Brightness lev el dum dum 0xC5 0xAA 0x7A byte4 ID C/S 0xC5 0xAA 0x7A byte 4 dum dum C/S ① byte4 = 0x00 ; Whole Operating OSD OFF dum dum C/S ① byte4 = this v alue(00~99 decimal) is Brightness lev el of Camera.
6.14.3 Set Negativ e mode 6.15 Reset 0xC5 0xA A 0x72 byte 4 ID 0xC5 0xAA 0x72 byte 4 dum C/S dum dum dum C/S ① byte4 = 0x00 ; Negativ e mode OFF 0xC5 0x4F 0x00 0x00 ID C/S 0xC5 0x4F 0x00 0x00 dum dum dum dum C/S dum dum C/S ① Reset u-COM, and POWER OFF & ON. ② byte4 = 0x01 ; Negativ e mode ON 6.14.4 Set Screen Inv ersion ( Full Mirror ) ON/OFF 0xC5 0xA A 0x7F byte 4 ID 0xC5 0xAA 0x7F byte4 dum 6.16 Read / Set status of Camera 6.16.
6.16.2 Read the current status 2 of the Camera 0xC5 0xA A 0x81 0x00 ID 0xC5 0xAA 0x81 0x00 byte5 6.17 Key Action 6.17.1 Key Action ( This action needs stop command ) C/S dum dum dum 0xC5 0x5F bye3 0x00 ID C/S 0xC5 0x5F byte 3 0x00 dum dum C/S ① byte5 is data contain the current status 2 of the Camera dum dum ② This action is f inished af ter y ou send 0xC5, 0x5F, 0x0C, 0x00, 0x01, 0x31. Bit7 N/C Bit6 N/C Key Code Bit5 N/C 0x00 No Key Action.
Key Code Description Key Code Description 0x13 Increase HUE in Manual WB mode 0x42 Increase IRIS level in only Iris Fix or MANUAL Exposure mode. 0x14 Decrease HUE in Manual WB mode 0x43 Decrease IRIS level in only Iris Fix or MANUAL Exposure mode.
6.18 Masking Priv acy Zone 6.18.1 Set the page of Priv acy Zone 6.18.3 Clear the Masking Priv acy Zone 0xC5 0x82 bye3 0x00 ID C/S 0xC5 0x82 byte 3 0x00 dum dum dum dum 0xC5 0x83 bye3 0x00 ID C/S 0xC5 0x83 byte 3 0x00 dum dum C/S dum dum C/S dum C/S ① byte3 = 0x00 ~ 0x05 ; the page which is to be cleared. ① byte3 = 0x00 ~ 0x05 ; There are 6 pages. 6.18.4 Set the Masking Priv acy Zone ② In order to mask Priv acy Zone, f irst of all the page must be chosen. 6.18.
7. Specifications M odel Nam e WDAC-2308X( NTSC ) WDAC-2308X( PAL ) Scanning Sys te m 2:1 Interlace Pick -up De vice 1/4" SONY New Super HAD CCD Total / Effective Pixels 410,000/380,000 Pixels 470,000/440,000 Pixels More than 49dB S/N Ratio H. Res olution More Than 470 TV Lines More Than 450 TV Lines Lens Spec. x23 Zoom, F1.6(WIDE) ~ F3.8(TELE), f = 3.8~87.4mm Le ns Cons truction 10 Elements in 7 groups ( including 2 asperical lenses ) M in. Illum inance 1.
8.
