SERVICE MANUAL 711380 REV. D
WELCH ALLYN UNIVERSAL DESK CHARGER 5
2.1 Incoming
Inspection
2.1.1 Inspect shipping package and product for
damage. Make a record of possible shipping
damage.
2.2.1 Tools required for service: Phillips screw driver,
repair test handle T17814.
NOTE: Any Welch Allyn rechargable
handle can be substituted for the T17814
repair test handle .
2.2.2 The repair test handle, Tool# T17814, can be
ordered from Welch Allyn by calling Customer
Service at 800-535-6663.
2.1.1 Apply main power to the unit and ensure that the
green LED light illuminates.
With main power applied, insert any Welch Allyn
nicad handle into one of the charging wells and
ensure that the amber charge LED under that well
lights. Repeat the test on the opposite charging
well.
2.2 Required Tools
2.3 Incoming
Operational Test
