Data Sheet

Data sheet

ClipCard
CC DIA 30 K MC NE WS
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 16
D-32758 Detmold
Germany
Fon: [phone]
Fax: [phone]
www.weidmueller.com
Technical data


Creation date October 13, 2016 11:55:39 AM CEST
 Catalogue status 12.10.2016 / We reserve the right to make technical changes. 2
Dimensions and weights

Length 30 mm

Length (inches) 1.181 inch
Width 30 mm

Width (inches) 1.181 inch
Net weight 1.75 g

Diameter 30 mm

General data

Application/manufacturer Self-adhesive, Ø 30 mm

Colour White
Length 30 mm

Material Polyamide 66
Operating temperature range, max. 60 °C

Operating temperature range, min. -40 °C
UL 94 flammability rating V-2

Version
Self-adhesive
Width 30 mm



Device markers

Diameter 30 mm
 

Classifications

ETIM 6.0 EC001288

eClass 6.2
27-14-91-29
eClass 9.0 27-40-06-29



Approvals

ROHS Conform

