Bolt-type screw terminals
WF 12
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 26
D-32758 Detmold
Germany
Fon: [phone]
Fax: [phone]
www.weidmueller.com
Technical data


Creation date 11 March 2020 11:28:25 CET
 Catalogue status 06.03.2020 / We reserve the right to make technical changes. 3
Stud connection

2 x cable lugs DIN 46 234 6 to 120 mm²

2 x cable lugs DIN 46 235 10...95 mm²
Cable lug to DIN 46234 6...120 mm²

Cable lug to DIN 46235 10...95 mm²
Impulse voltage with epoxy resin
partition plate 12 kV

Stud size for spade connection
M 12
Tightening torque, max. 31 Nm

Tightening torque, min.
14 Nm
Voltage with epoxy resin partition plate 2,300 V



UL rating data

Certificate No. (UR) E60693

Conductor size Factory wiring max. (UR) 250 kcmil
Conductor size Factory wiring min. (UR) 10 AWG

Conductor size Field wiring max. (UR) 250 kcmil
Conductor size Field wiring min. (UR) 10 AWG

Current size C (UR)
255 A
Voltage size C (UR) 1000 V



Classifications

ETIM 6.0 EC000897

ETIM 7.0 EC000897
eClass 9.0 27-14-11-20

eClass 9.1 27-14-11-20
eClass 10.0 27-14-11-20

UNSPSC 30-21-18-01

