Datasheet

Data sheet

Bolt-type screw terminals
WF 12
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 26
D-32758 Detmold
Germany
Fon: [phone]
Fax: [phone]
www.weidmueller.com
Technical data


Creation date 11 March 2020 11:28:25 CET
 Catalogue status 06.03.2020 / We reserve the right to make technical changes. 2
Dimensions and weights

Width 33.8 mm

Width (inches) 1.331 inch
Height 67 mm

Height (inches) 2.638 inch
Depth 70.5 mm

Depth (inches)
2.776 inch
Net weight 102.6 g



Temperatures

Storage temperature, max. 40 °C

Storage temperature, min. 10 °C
Storage temperature 10 °C...40 °C

Continuous operating temp., min.
-50 °C
Continuous operating temp., max. 120 °C



Material data

Material Wemid

Colour
dark beige
UL 94 flammability rating V-0



System specifications

Version Single-stud terminals

End cover plate required No
Number of levels 1

Number of clamping points per level 1
Levels cross-connected internally No

PE connection
No
Rail TS 35



Additional technical data

Explosion-tested version No

Number of similar terminals 1
Open sides Open

Type of mounting Snap-on

CSA rating data

Certificate No. (CSA) 200039-1244019

Current size C (CSA) 320 A
Voltage size C (CSA) 1000 V

Wire cross section max. (CSA)
250 kcmil
Wire cross section min. (CSA) 10 AWG



Conductors for clamping (rated connection)

2 x cable lugs DIN 46 234 6 to 120 mm²

2 x cable lugs DIN 46 235 10...95 mm²
Cable lug to DIN 46234 6...120 mm²

Cable lug to DIN 46235 10...95 mm²
Clamping range, max. 120 mm²

Clamping range, min. 6 mm²
Number of connections 1

Stud size for spade connection M 12
Tightening torque, max. 31 Nm

Tightening torque, min.
14 Nm
Type of connection Threaded stud connection



Rating data

Rated cross-section 120 mm²

Rated voltage 1,000 V
Voltage with epoxy resin partition plate 2,300 V

Rated current 269 A
Current at maximum wires
269 A

Volume resistance according to IEC
60947-7-x 0.12 mΩ
Power loss in accordance with IEC
60947-7-x 8.61 W

Rated impulse withstand voltage
8 kV
Impulse voltage with epoxy resin
partition plate 12 kV

Pollution severity
3

