Data Sheet
Datenblatt
W-Series
WNT 4 10X3
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 16
D-32758 Detmold
Germany
Fon: +49 5231 14-0
Fax: +49 5231 14-292083
www.weidmueller.com
Technische Daten
Erstellungs-Datum December 13, 2013 11:05:21 AM CET
Katalogstand xx.xx.xxxx / Technische Änderungen vorbehalten 3
Rated data
Rated cross-section 4 mm²
Rated voltage 400 V
Rated impulse withstand voltage 6 kV
Rated current 32 A
Current at maximum wires 41 A
Standards
IEC 60947-7-1
Pollution severity 3
UL ratings data
Certificate No. (UR) E60693
Voltage size C (UR) 600 V
Current size C (UR) 35 A
Conductor size Factory wiring max. (UR) 10 AWG
Conductor size Factory wiring min. (UR) 26 AWG
Conductor size Field wiring max. (UR) 10 AWG
Material data
Material Wemid
Colour
Blue
UL 94 flammability rating V-0
System specifications
Product family W-Series
Type of connection Busbar connection
Connection direction on side
Number of levels 1
Number of connections 1
No. of clamping points per level 1
Levels cross-connected internally No
End cover plate required Yes
Classifications
ETIM 3.0 EC001257
UNSPSC 30-21-18-11
eClass 5.1 27-14-11-38
eClass 6.2
27-14-11-38
eClass 7.1 27-14-11-38
Product information
Descriptive text technical data Tightening torque, N-isolator 0.4..0.8 Nm
Approvals
Approvals
ROHS Conform
Downloads
STEP 1010780000_08992_WNT_4_10X3_STP.stp
