User Documentation

Weidmüller Interface GmbH Co. KG; Klingenbergstraße 16, 32758 Detmold-Germany
Order No
Version: ZDUB 2.5-2/2AN/RC* 1712820000
ZDUB 2.5-2/4AN/RC* 1712970000
Type Order No
ZAP ZDUB* 1704750000
ZTW ZDUB 1704340000
Plugable* Order No
ZQB 2.5-2* 1677120000
- Type Wemid
CTI
≥
600
V0
-60°C…+110°C (insulating material limit)
-60°C…+40°C (for T6 applications)
-60°C…+55°C (for T5 applications)
- Ambient temperature range -60°C…+70°C (for T4 applications)
* in all colours
- Ambient temperature range
INSTALLATION INSTRUCTIONS
& CONDITIONS FOR SAFE USE
II 2 GD
Ex eb IIC
Modular TERMINAL Blocks: Z- Series
IECEx ULD 16.0036U
DEMKO 16 ATEX 1808U
Notified Body No. of Ex - QA: 0344
Label print on package unit: 0344
Standards:
EN 60079-0:2012 + A11 2013 and EN 60079-7:2015
IEC 60079-0: 6 th Edition and IEC 60079-7: 5 th Edition
in conjunction with:
Modular Terminal Blocks: ZDUB
Cross-connection
Accessories:
end plate
partions plate
- Ambient temperature range
Insulation material:
- Operating temperature range
- Tracking resistance (A) to IEC 60112
- Flammability class to UL 94
Version: ZDUB 2,5-2/.../RC; 1353240 Index: 00 Date: 12.2018
1
