WPD 233
1100 V
520 A / ΔT 40 K
≤ 40 K / 520 A
0,02mΩ
- Conductor cross section (input = output)
solid stranded
Finely stranded
with wire end
ferrule
Tightening
Torque
rated conductor cross section:
150-300 mm² 150-300 mm² 120-240 mm² 45 Nm
conductor cross section, American Wire Gauge:
300 - 600 kcmil 300 - 600 kcmil 250-500 kcmil 33,9 Nm
Auxiliary connection
rated conductor cross section:
1,5 - 10 mm²
1,5 - 10 mm² 1,5 - 6 mm² 1,2 Nm
conductor cross section, American Wire Gauge:
16 - 8 AWG 16 - 8 AWG 16 - 10 AWG 1,2 Nm
Model: WPD 233
Screw (direct)
mounting with
screw acc. to
DIN 4762
1100
TS 35 mounting
1100
For busbar
(Flexibar) with
screw mounting
NA
For busbar
(Flexibar) with
TS35 mounting
NA
Model:
WPD 233
current [A]: 520
Model WPD 233
Wire type
Left Center Right
Solid
- 150…300mm² -
Stranded
- 150…300mm² -
Flexible with ferrule
- 120…240mm² -
Wire type
Left Center Right
Solid
- 150…300mm² 1.5…10mm²
Stranded
- 150…300mm² 1.5…10mm²
Flexible with ferrule
- 120…240mm² 1.5…6mm²
- Rated voltage
- Rated current
- Temperature rise with rated current
Technical data according to IEC/EN 60079-7 (increased safety "e", protection level "eb"):
- Contact resistance
with rated conductor, 35 mm²
Electrical Data:
Rated incoming currents
Max. rated voltage [V]:
Rated conductor cross sections
Incoming connection
Outgoing connections
