User Documentation

Data sheet
W-Series
WPD 231 2X95/2X95 GY
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 16
D-32758 Detmold
Germany
Fon: [phone]
Fax: [phone]
www.weidmüller.com
Conductor connection data
Input (x2) / Output (x2)
Copper Alluminium
95 mm
2
70 mm
2
50 mm
2
35 mm
2
25 mm
2
16 mm
2
10 mm
2
Max. currrent at 2x 95 mm
2
(according to IEC)
Stripping lenghts
19 Nm
16 Nm
26 mm
Copper Alluminium
AWG 3/0
AWG 2/0
AWG 1/0
AWG 2
AWG 4
AWG 6
AWG 8
Stripping lenghts
26 mm
Input (x2) / Output (x2)
2
Catalogue status 12.02.2019 / We reserve the right to make technical changes.
Max. currrent at 1x 95 mm
2
(according to UL)
19 Nm
14 Nm
400 A
200 A
155 A360 A
Drawings
Auxiliary connectin
Copper
10 mm
2
6 mm
2
4 mm
2
2.5 mm
2
1.5 mm
2
Max. currrent
Stripping lenghts
57 A
10 mm
Copper
AWG 8
AWG 10
AWG 12
AWG 14
AWG 16
Max. currrent
Stripping lenghts
57 A
10 mm
1.2 Nm
1.2 Nm
20.3Lb
In.
20.3Lb
In.
Stranded
Solid core
Finely stranded with
wire-end ferrule
Sector shaped
Stranded
Solid core
Finely stranded with
wire-end ferrule
Sector shaped
22.6 Nm
22.6 Nm
200Lb In.
200Lb In.
200Lb In.
200Lb In.
Allen screw M14 (SW 6 mm)
Allen screw M14 (SW 6 mm)
Screw M4 (+/- PZ2)
Screw M4 (+/- PZ2)
