8 Processdata | Fieldbus-dependent process data widths
53Manual Communication module UR20-4COM-IO-LINK2547720000/03/09.2019
UR20-FBC-EIP
You can select the length of the process input data and the
length of the process output data independently of each
other.
Process data for IO-Link devices Fieldbus dependent data widths
1)
Input Output Input Output
Byte Byte Byte Byte
0 ... 128 0 ... 128 2...130 2...130
1) incl. 2 Byte module process data
UR20-FBC-DN
You can select the length of the process input data and the
length of the process output data independently of each
other.
Process data for IO-Link devices Fieldbus dependent data widths
1)
Input Output Input Output
Byte Byte Byte Byte
0 ... 128 0 ... 128 2...130 2...130
1) incl. 2 Byte module process data
UR20-FBC-CAN
You can select the length of the process input data and the
length of the process output data independently of each
other.
Process data for IO-Link devices Fieldbus dependent data widths
1)
Input Output Input Output
Byte Byte Byte Byte
0 ... 62 0 ... 62 2...64 2...64
1) incl. 2 Byte module process data
