8 Processdata | Fieldbus-dependent process data widths
51Manual Communication module UR20-4COM-IO-LINK2547720000/03/09.2019
8.4 Fieldbus-dependent process data widths
The following tables show which process data lengths are
available for the individual couplers, and the relevant eld-
bus-dependent data widths.
UR20-FBC-PB-DP
Process data for IO-Link devices Fieldbus dependent data widths
1)
Input Output Input Output
Byte Byte Byte Byte
4 4 6 6
8 8 10 10
16 16 18 18
32 32 34 34
16 8 18 10
32 16 34 18
32 8 34 10
1) incl. 2 Byte module process data
UR20-FBC-PN-IRT
Process data for IO-Link devices Fieldbus dependent data widths
1)
Input Output Input Output
Byte Byte Byte Byte
4 4 7 7
8 8 11 11
16 16 19 19
32 32 35 35
64 64 67 67
128 128 131 131
16 8 19 11
32 16 35 19
32 8 35 11
64 8 67 11
64 16 67 19
64 32 67 35
128 8 131 11
128 16 131 19
128 32 131 35
128 64 131 67
1) incl. 2 Byte module process data
