OPC UA Server

System manual

2696790000/02/04.2020

Designation Description

ShowVariableTree Display of generic variable tree (1 = activated, 0 = deactivated)

Example

[OpcUa]

[OpcUa.Application]

Port=4840

ApplicationName="SampleApplicationName"

ApplicationURI="SampleApplicationURI"

ProductURI="http://www.company.com/"

ProductName="OPC-UA Server"

Manufacturer Name="Sample Manufacturer"

ShowVariableTree = 1 // 1 = activate, 0 = deactivate

"SecureChannel"configurations

With an encrypted connection, the Basic256Sha256 encryption algorithm is

supported with 2 different setting options (Sign and Sign and Encrypt). All

configuration values can be configured via integer values.

Security Policy Value

Basic256Sha256 3

Message Mode Value

Sign 1

Sign and Encrypt 2

Information

The "Basic256" and "Basic128Rsa15" encryption algorithms are no longer

supported because they no longer meet current security requirements.

Example (default setting)

[OpcUa]

// Policy 3 = Basic256Sha256

// MessageMode 1 = Sign, 2 = SignAndEncrypt

[OpcUa.Security.CommunicationChannel.Communication:0]

Policy=3

MessageMode=1

[OpcUa.Security.CommunicationChannel.Communication:1]

Policy=3

MessageMode=2

Additional communication channels (CommunicationChannel) with different

security settings can be added. Each additional connection is declared with

an ascending number. The number must be unique. The Policy and Mes-

sageMode entries must always be set for each connection.

"Subscription" configuration

For the "Subscription" service, the supported time intervals can be config-

ured. By default, 50 ms is set for the minimum and 3 600 000 ms for the

maximum limit.
