Configuration

System manual

2696790000/02/04.2020

6 Configuration

The combined switching of the assemblies and modules in u-create studio

that took place during the hardware installation is re-created with the config-

uration..

The control configuration is based on the device descriptions. These de-

scribe the basic configuration specifying which parameterization options are

available. The control configuration allows the connection of I/O modules as

well as fieldbus modules. Additional elements are available depending on

the installed device descriptions.

The available I/O channels are indicated in the u-create studio control con-

figuration and can be utilized in the application.

Information

Additional information as well as the exact parameter description of individ-

ual modules can be found in the online help of u-create studio.

The network configuration of the control is also possible vie Service App

"DevAdmin" (see 9 Device Administration (DevAdmin)).

6.1 Data exchange between control and visualization

IEC system variables that have been added to a symbol file can be used by

a visualization to display process values and allow operators to modify appli-

cation variables.

u-create studio makes the so-called symbol file available for the exchange of

system variables. The symbol file contains the IEC variables of the u-create

studio project.

For detailed information about configuration or data exchange, please see

the respective online help (u-create studio).
