Appendix: Tutorial - call C function from IEC

System manual

2696790000/02/04.2020

124

22 Appendix: Tutorial - call C function from IEC

The u-create system offers the possibility to call C functions in IEC created

with u-create studio C++.

Therefore a template with a predefinded interface for data exchange exists

in u-create studio C++. It is recommanded to create a function in IEC which

takes care of the call of the C function and the correct data exchange. The

data exchange itself takes place on a shared memory area. Because of this

only adresses on the memory area are transfered. The data types from IEC

and C are not compatible, so on transfer of the parameters it must be payed

attention on the correct type convertion.

Information

There is no automatically type checking. The user himself is responsible for

the correct mapping. E.g. if the size of the data types does not match, a

wrong memory area is accessed.

The example in this chapter describes the creation of a C function in u-cre-

ate studio C++ and the call in a IEC application created inu-create studio.

22.1 Preconditions and needed components

The following components are necessary:

● u-create studio C++

● u-create studio

● u-create studio project with an executable IEC application

● Fitting hardware

The creation of this example requires basic knowledge in dealing with u-cre-

ate studio and u-create studio C++.

22.2 Task

In this example application a self made C function should be called via an

IEC function in the IEC application. The IEC function provides 3 local vari-

ables with different data types (DWORD, STRING[106] and REAL) and a global

variable of type DWORD. The values of the variables should be changed in the

C function as follows:

● The global variable of type DWORD should be summated with the variable

of type DWORD

● The variable of type REAL should be multiplicated with 3.

● The variable of type STRING[106] should be extended with characters.

● The return value of the C function should be twice as much as the vari-

able of type DWORD.
