User Documentation

- 5 -
ATEX Information
1. Certificate number DEMKO 11 ATEX 150188X
2. Ambient range: -40°C ≤ Tamb ≤ +75°C
3. Certification String: Ex nA nC IIC T4 Gc
4. Applicable standards: EN 60079-0:2012+A11:2013, EN 60079-15:2010
5. The conditions of safe usage:
a. The Ethernet Communication Devices are intended for mounting in an
IP54 enclosure and used in an area of not more than pollution degree 2 as
defined by IEC60664-1
b. Conductors suitable for use in an ambient temperature of 93°C must be
used for the Power Supply Terminal.
c. A 4mm
2
conductor must be used when connection to the external
grounding screw is utilized.
d. PROVISIONS SHALL BE MADE, EITHER IN EXTERNAL TO THE
APPARATUS, TO PREVENT THE RATED VOLTAGE BEING
EXCEEDED BY THE TRANSIENTS DISTURBANCES OF MORE
THAN 40 %.
Wiring Requirements
WARNING
Do not disconnect modules or wires unless the power supply has
been switched off or the area is known to be non-hazardous. The
devices may only be connected to the supply voltage shown on
the type plate.
The devices are designed for operation with a Safety Extra-Low
Voltage. Thus, they may only be connected to the supply voltage
connections and to the signal contact with the Safety Extra-Low
Voltages (SELV) in compliance with IEC950/ EN60950/
VDE0805.
WARNING
Substitution of components may impair suitability for Class I,
Division 2, and Zone 2. These devices must be supplied by an
SELV source as defined in Low Voltage Directive 73/23/EEC
and 93/68/EEC.
WARNING
This unit is a built-in type. When the unit is installed in another
piece of equipment, the equipment enclosing the unit must
comply with fire enclosure regulation IEC 60950/EN60950 (or
similar regulation).
