PCN-PN48-20190717-00-A

Page 1

Technical change to IE-SW-PL08M-series

(8-Port Fast Ethernet managed Switches)

Dear Madam or Sir,

the products listed below are subject to a product change and will be supplied in a modified revision. Please

pass this product information on to your employees and, if needed, to your customers. All modifications

mentioned have been made to support our ongoing commitment to continual improvement and ongoing product

development.

1. Initial situation

2. Technical changes

Product revision change due to phase out of used power regulator.

1.) Add 12/48 VDC input voltage

Article

Input voltage

name

number

current version

new version

IE-SW-PL08M-8TX

1241040000

24 VDC

12/24/48 VDC

IE-SW-PL08MT-8TX

1286780000

24 VDC

12/24/48 VDC

IE-SW-PL08M-6TX-2SC

1241070000

24 VDC

12/24/48 VDC

IE-SW-PL08MT-6TX-2SC

1286790000

24 VDC

12/24/48 VDC

IE-SW-PL08M-6TX-2ST

1241080000

24 VDC

12/24/48 VDC

IE-SW-PL08MT-6TX-2ST

1286800000

24 VDC

12/24/48 VDC

IE-SW-PL08M-6TX-2SCS

1241090000

24 VDC

12/24/48 VDC

IE-SW-PL08MT-6TX-2SCS

1286810000

24 VDC

12/24/48 VDC

2.) Operating temperature range extended (for standard temperature models).

Article name

Article

number

Operating temperature

current version

Operating temperature

new version

IE-SW-PL08M-8TX

1241040000

0°C to 60°C

-10°C to 60°C

IE-SW-PL08M-6TX-2SC

1241070000

0°C to 60°C

-10°C to 60°C

IE-SW-PL08M-6TX-2ST

1241080000

0°C to 60°C

-10°C to 60°C

IE-SW-PL08M-6TX-2SCS

1241090000

0°C to 60°C

-10°C to 60°C

Summary of content (5 pages)

PAGE 1
Product Change Notification PCN-PN48-20190717-00-A Page 1 Technical change to IE-SW-PL08M-series (8-Port Fast Ethernet managed Switches) Dear Madam or Sir, the products listed below are subject to a product change and will be supplied in a modified revision. Please pass this product information on to your employees and, if needed, to your customers. All modifications mentioned have been made to support our ongoing commitment to continual improvement and ongoing product development. 1.
PAGE 2
Product Change Notification PCN-PN48-20190717-00-A Page 2 3.) ST-connector material changed from metal to plastic. Article name IE-SW-PL08M-6TX-2ST IE-SW-PL08MT-6TX-2ST Article number 1241080000 1286800000 ST-Connector material Current version Metal Metal ST-Connector material New version Plastic Plastic 4.) Position of ground screw at switch´s top panel changed with new product version. Valid for products in table below. Refer to below figure for more details.
PAGE 3
Product Change Notification PCN-PN48-20190717-00-A Page 3 5.) Position of LEDs, ports (fiber optic/copper) changed with new product version. Valid for products in table below. Refer to below figure for more details. Article name IE-SW-PL08M-8TX IE-SW-PL08MT-8TX IE-SW-PL08M-6TX-2SC IE-SW-PL08MT-6TX-2SC IE-SW-PL08M-6TX-2ST IE-SW-PL08MT-6TX-2ST IE-SW-PL08M-6TX-2SCS IE-SW-PL08MT-6TX-2SCS Current version (1.2.
PAGE 4
Product Change Notification PCN-PN48-20190717-00-A Page 4 6.) DNV-GL approval for new product revision will not be renewed.
PAGE 5
Product Change Notification PCN-PN48-20190717-00-A Page 5 6. Data - PCN-number: PCN-PN48-20190717-00-A date of publishing: 17th July 2019 revision number: A We hope that the changes will benefit your business and will not affect you in any significant way and apologies in case of any inconvenience caused. Please rest assured that we will do everything possible to achieve this product change as smoothly as possible with minimum or no business disruption.
