-8 -
CAUTION:
• The built-in LED light is designed
to illuminate the small work area
temporarily.
• Do not use it as a substitute for a
     
have enough brightness.
• LED light turns off when the tool has
not been used for 5 minutes.
Caution: DO NOT STARE INTO BEAM.
Use of controls or adjustments or performance

may result in hazardous radiation exposure.
•
Bit-locking Function
With the switch at off and the bit locked in
place, the tool can be used as a manual
screw-driver-up to 14.7 N·m (150 kgf-cm,
130 in-lbs).
There will be a little play in the driving shaft,
but this is not a malfunction.
•
Main Switch (ON/OFF)
Push the upper half of the switch for for-
ward rotation, or the lower half for reverse
rotation.
•
Speed Selector Switch
To suit the application of this tool, two
different rotational speeds are available.
Depending upon use, either the high or low
speed should be selected
Speed selection Torque
LOW 200 min
-1
(rpm) High
HIGH 600 min
-1
(rpm) Low
CAUTION
• Check speed selector switch before use.
• Do not operate the speed selector switch
while the main switch is on (switch is in
the ON position).
•
Main Switch Lock
After use, set the main switch lock at the lock
position to prevent accidental operation.
•
Battery Pack
CAUTION:
1. Remove the battery pack away from
the tool.
2. Charge the battery pack using the
battery charger.
Forward
HIGH
Forward
Reverse
Main switch lock
Lock
Reverse
LOW
