V. SPECIFICATIONS
MAIN UNIT
Model 1479120000
Capacity
Screw
driving
Machine screw M2.5 – M5
Wood screw ø 3.8 x 38 mm (5/32” x 1-29/64”)
Drilling For metal ø 5 mm (13/64”) spc t = 1.6 mm
Motor 3.6 V DC
No load speed
LOW: 200 min-1 (rpm)
HIGH: 600 min-1 (rpm)
Maximum torque
LOW: 4.4 N·m (45 kgf-cm, 39 in-lbs)
HIGH: 1.5 N·m (15 kgf-cm, 13 in-lbs)
Maximum clutch torque 3.0 N·m (30 kgf-cm, 26 in-lbs)
Overall length 276 mm (10-55/64")
Weight (with battery pack) 0.5 kg (1.1 lbs)
BATTERY PACK
Model 1479110000
Storage battery Li-ion Battery
Battery voltage 3.6 V DC (3.6 V x 1 cell)
BATTERY CHARGER
Model 9007460000
Weight 0.6 kg (1.3 lbs)
Electrical rating See the rating plate on the bottom of the charger.
Charging time
2.4 V 3.6 V
9007450000 1479110000
Full 45 min.
NOTE:
• For applicable battery packs to this charger, see the label on the charger or the latest
general catalog.
The instruction label on the battery packs also shows the applicable charger.
Full 30 min.
