Troubleshooting
8.3 Replacing cutting blades
CAUTION
Risk of injury posed by sharp blades
► Use forceps to change the blades.
► Dispose of the removed blades in a sepa-
rate container.
All present blades must be replaced each time
the knife is changed.
► Remove the protective cover and the chute.
2
1
Figure 8.1 Cutting blade
► Loosen the xing screws (1) (Allen key 2.0 mm).
► Remove the blades (2).
► Align the new blades so that the bevelled edges are
turned away from one another.
Figure 8.2 Aligning the blades
► Insert the new blades.
► Screw both xing screws back on tightly.
► Reattach the chute and the protective cover.
8.4 Replacing the fuses
► Make sure that the machine is switched o󰀨.
► Remove the power plug.
1
Figure 8.3 Opening the fuse compartment
► Lever the fuse compartment (1) out of the mains lter
unit using a slotted screwdriver.
► Replace both fuses with new ones (2 x T2AH250V).
► Put the fuse compartment back into the mains lter unit.
