User Documentation
Setting up the machine
2583070000/00/04.201832
5.14 Programming structure
Name Authorization
1)
Options Default Description
1. Production menu I
2. Wiring data I
3. User menu I
4. USB data II
5. Programs II
6. Settings
Language II German / English /
French
English
Short program II 1 / 0 1 1 standard parameter modiable
0 further parameters modiable
Memory locations program II 1 ... 2000 Subdivision of program positions
Cable monitoring II 1 / 0 1 Cable between feed rollers
0-cut II 1 / 0 1 Zero-overlap cut at program start
PC start II 1 / 0 0 Start command via WI manager
Ramp motor II 1-10 5 Ramping up after switch-on
1= fast, 10 = slow
Speed II 0.1 ... 1.5 m/s 1.5 Feed speed of the cable feed
Correction II -99...+99 mm Length correction of cable feed
Timeout position III 0 ... 99 s 50
Program waiting time III 0 ... 100 s
Motor increments III 1 ... 9999 inc/U 2000
Path/Motor rpm III 1 ... 999.9999 mm per
turn
36.4425
Max. power feed III 0 ... 255 95
Max. power cutting III 0 ... 255 50
Machine type
Machine number
7. Operating data II Delete day counter
III Delete all programs
III Factory settings
8. Manual operation III
9. Test inputs III
10. Test outputs III
1) Authorization: I = Operator, II = Installer, III = Technician
