Setting up the machine
5.8 Resetting the daily piece quantity
Open Menu 7.
Continuously press C for at least 5 seconds.
The daily piece quantity is reset to zero.
5.9 Setting cable monitoring function
If this function is active, the machine detects whether there
is a wire between the feed rollers.
Open the menu item “Cable monitoring” in Menu 6.
Use the arrow keys to select the required setting (1 =
active, 0 = not active).
Press E to save the setting.
5.10 Setting the zero-overlap cut
If this function is active, a zero-overlap cut is carried out at
the start of every program.
Open the menu item “0-cut” in Menu 6.
Use the arrow keys to select the required setting
(1 = active, 0 = not active).
Press E to save the setting.
5.11 Setting the program start
If this function is active, the machine is started via a linked
PC and not via the start button.
Open the menu item “PC start” in Menu 6.
Use the arrow keys to select the required setting
(1 = active, 0 = not active).
Press E to save the setting.
5.12 Setting the start-up speed
The speed with which the machine ramps up after being
switched on can be modied.
Open the menu item “Ramp motor” in Menu 6.
Use the arrow keys to select the required setting
(1 = fast, 10 = slow).
Press E to save the setting.
5.13 Setting the length correction function
You can correct the cable feed via the length correction
function.
Open the menu item “Correction” in Menu 6.
Use the arrow keys to select the required value
(-99 mm... +99 mm).
Press E to save the setting.
