Periodic proof test procedure
14 1482850000/01/11.2017
11. Periodic proof test procedure
Step
Action
1
Bypass the safety PLC or take other appropriate action to avoid a false trip.
2
Connect a simulator identical to the input setup.
3
Apply input value corresponding to 0/100 % output range to each channel.
4
Observe whether the output channel acts as expected.
5
Restore the input terminals to full operation.
6
Remove the bypass from the safety PLC or otherwise restore normal operation.
This test will detect approximately 95 % of possible “DU” (dangerous undetected) failures in the pulse
isolator. The proof test is equivalent to the functional test.
