User Documentation

Weidmüller Interface GmbH Co. KG; Klingenbergstraße 16, 32758 Detmold-Germany
I
max
: 57A 57 A 31,5 A
250 V
250 V
250 V
AAP21 10 LO.../ 3 x AAP21 4 LI… AAP21 10 LO.../ 3 x AAP21 4 DT AAP21 10 LO.../ 5 x AAP21 4 FS
I
max
: 6,3 A | 20 A
250 V
AAP21 10 LO.../ AAP21 4 FS/ 3 x AAP21 4 LI... | AAP21 10 LO.../ AAP21 4 DT/ 3 x AAP21 4 LI…
I
max
: 18,9 A | 57 A | 57 A
250 V
AAP21 10 LO/ 3 x AAP21 4 FS | AAP21 10 LO.../ 3 x AAP21 4 DT | AAP21 10 LO.../ 3 x AAP21 4 LI…
Please attend the details in the technical
data above.
Please attend the details in the technical
data above.
Please attend the allocated current
in the technical data above.
IECEx / ATEX Terminal and Cross-Connection Arrangements:
Application Case
Information for further cross-connector arrangements will be provided on request.
A - Continuous feed in with supply terminal and share with distribution terminal blocks
Max voltage data according to IEC/EN 60079-7 in conjunction with
protective earth terminal blocks of the A-Series, (increased safety "ec"):
Version: AAP21 10 LO;12072844 ; Index: 01; Date: 04.2018
3
