Data Sheet

Data sheet
HDC enclosures
HDC 48B SDLU 1M32G
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 16
D-32758 Detmold
Germany
Fon: +49 5231 14-0
Fax: +49 5231 14-292083
www.weidmueller.com
Technical data
Creation date May 27, 2019 11:35:30 PM CEST
Catalogue status 23.05.2019 / We reserve the right to make technical changes. 2
Dimensions and weights
Width 166.2 mm
Width (inches) 6.543 inch
Height 120 mm
Height (inches) 4.724 inch
Depth 143 mm
Depth (inches) 5.63 inch
Mounting dimension - width 111 mm
Mounting dimension - height
106 mm
Net weight 1,715 g
Temperatures
Limit temperature -40 °C ... 125 °C
Environmental Product Compliance
REACH SVHC Lead 7439-92-1
Dimensions
Cable entry w. threading
Height of base B1 10 mm
Height of housing B 120 mm
Hole pitch length A2 111 mm
Total length housing 132 mm
Width base C1
120 mm
Width housing C 90 mm
General data
EMC housings No
Housing main material diecast aluminium
Material of locking element
Stainless steel, rust-proof
Protection class note Protection classwith
secured cover: IP 65
Protection degree IP65
Surface finish Powder coating
Version
Cable entry w. threading
Clamp version End-locking clamp
Cover with cover
Design Standard
Design of cover with cover
Design of housing Base enclosure
Design of locking system End-locking clamp, lower
side
Internal thread
M 32
Number of cable entry on top 0
Number of cable entry sideways 1
Sealing NBR
Size 12
Size of cable entries
M 32
Suitable for ModuPlug
®
Yes
Top part/bottom part/lid lower part
Type Base housing
Classifications
ETIM 3.0 EC000437
ETIM 4.0 EC000437
ETIM 5.0 EC000437
ETIM 6.0 EC000437
UNSPSC 30-21-18-01
eClass 5.1 27-14-34-19
eClass 6.2 27-26-12-03
eClass 7.1 27-44-02-02
eClass 8.1 27-44-02-02
eClass 9.0
27-44-02-02
eClass 9.1 27-44-02-02
