Data Sheet
Data sheet
HDC insert
HDC S4 SAS
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 16
D-32758 Detmold
Germany
Fon: +49 5231 14-0
Fax: +49 5231 14-292083
www.weidmueller.com
Technical data
Creation date May 27, 2019 3:16:04 PM CEST
Catalogue status 23.05.2019 / We reserve the right to make technical changes. 3
Power contact
Clamping range, power contact, max. 6 mm²
Clamping range, power contact, min. 2.5 mm²
No. of poles, performance contact
4
Rated current (DIN EN 61984), power
contact 40 A
Rated impulse voltage (DIN EN 61984),
power contact 8 kV
Rated voltage (DIN EN 61984), power
contact 1,000 V
Stripping length, performance contact 8 mm
Tightening torque, power contact, max. 1.7 Nm
Tightening torque, power contact, min. 1.1 Nm
Type of connection, power contact Axial screw connection
Version
Clamping screw M 7 x 0.75 mm
Conductor cross-section, max. 6 mm²
Conductor cross-section, min. 2.5 mm²
Material Copper alloy
Size 3
Stripping length, rated connection 8 mm
Surface finish Silver passivated
Type of connection Axial screw connection
Volume resistance
≤ 1 mΩ
Wire connection cross section AWG,
max. AWG 11
Wire connection cross section AWG,
min. AWG 14
Wire connection cross section, finely
stranded, max. 6 mm²
Wire connection cross-section, finely
stranded with wire-end ferrules DIN
46228/4, max. 6 mm²
Wire connection cross-section, finely
stranded with wire-end ferrules DIN
46228/4, min. 2.5 mm²
Wire connection cross-section, finely
stranded, min. 2.5 mm²
Wire cross-section, solid, max.
6 mm²
Wire cross-section, solid, min. 2.5 mm²
Classifications
ETIM 3.0 EC002413
ETIM 4.0 EC001121
ETIM 5.0 EC001121
ETIM 6.0 EC000438
UNSPSC 30-21-18-01
eClass 5.1 27-14-34-19
eClass 6.2 27-26-12-90
eClass 7.1 27-44-02-90
eClass 8.1 27-44-02-90
eClass 9.0
27-44-02-05
eClass 9.1 27-44-02-05
Approvals
Approvals
ROHS Conform
Downloads
Brochure/Catalogue CAT 3 HDC 17/18 EN
FL FIELDWIRING EN
Engineering Data EPLAN, WSCAD, Zuken E3.S
Engineering Data STEP
