Data Sheet
Data sheet
HDC insert
HDC S4 SAS
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 16
D-32758 Detmold
Germany
Fon: +49 5231 14-0
Fax: +49 5231 14-292083
www.weidmueller.com
Technical data
Creation date May 27, 2019 3:16:04 PM CEST
Catalogue status 23.05.2019 / We reserve the right to make technical changes. 2
Dimensions and weights
Width 34 mm
Width (inches) 1.339 inch
Height 41.3 mm
Height (inches) 1.626 inch
Depth 51 mm
Depth (inches)
2.008 inch
Net weight 78.7 g
Temperatures
Limit temperature -40 °C ... 125 °C
Environmental Product Compliance
REACH SVHC Lead 7439-92-1
Dimensions
Height of plug 41.3 mm
Total length base 51 mm
General data
Conductor cross-section
6 mm²
Insulating material PC glass-fibre reinforced
(UL-listed and railway-
certified)
Insulating material group
IIIa
Insulation strength
10
10
Ω
Material Copper alloy
No. of poles 4
No. of power contacts 4
Plugging cycles, silver ≥ 500
Pollution severity 3
Rated current (DIN EN 61984) 40 A
Rated impulse voltage (DIN EN 61984) 8 kV
Rated voltage (DIN EN 61984) 1,000 V
Rated voltage according to UL/CSA 600 V AC/DC
Series MixMate
Size 3
Surface finish Silver passivated
Type Pin
UL 94 flammability rating
V-0
Volume resistance ≤ 1 mΩ
Connection data PE
Blade size, slotted (PE connection) SD 0.6 x 3.5
Connection type PE Screw connection
Fixing screw M 4
Rated cross-section 6 mm²
Stripping length PE connection 8 mm
Tightening torque, max. PE connection 0.8 Nm
Tightening torque, min. PE connection
0.5 Nm
Wire connection cross section, finely
stranded, max. 6 mm²
Wire connection cross-section, finely
stranded with wire-end ferrules DIN
46228/4, max. 6 mm²
Wire connection cross-section, finely
stranded with wire-end ferrules DIN
46228/4, min. 2.5 mm²
Wire connection cross-section, finely
stranded, min. 2.5 mm²
Wire cross section, AWG (PE), max.
AWG 11
Wire cross section, AWG (PE), min. AWG 14
Wire cross-section, solid, max.
6 mm²
Wire cross-section, solid, min. 2.5 mm²
