Data Sheet
Data sheet
W-Series
WPD 105 1x35+1x16/2x25+3x16 GY
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 16
D-32758 Detmold
Germany
Fon: +49 5231 14-0
Fax: +49 5231 14-292083
www.weidmueller.com
Technical data
Creation date May 27, 2019 1:59:59 PM CEST
Catalogue status 23.05.2019 / We reserve the right to make technical changes. 2
Dimensions and weights
Width 35.6 mm
Width (inches) 1.402 inch
Height 70 mm
Height (inches) 2.756 inch
Depth 53.7 mm
Depth (inches)
2.114 inch
Net weight 138 g
Temperatures
Storage temperature, max. 40 °C
Storage temperature, min. 10 °C
Storage temperature 10 °C...40 °C
Continuous operating temp., min.
-50 °C
Continuous operating temp., max. 130 °C
Environmental Product Compliance
REACH SVHC Lead 7439-92-1
Material data
Material Wemid
Colour
Light Grey
UL 94 flammability rating V-0
System specifications
Version
Screw connection
Tightening torque (clamping screw for
aluminium conductors)
11.3...35 Nm (35 mm²) /
5.1...16 Nm (16 mm²)
Tightening torque (clamping screw for
copper conductors)
3.5 Nm (35 mm²) / 2.5
Nm (25 mm²)
End cover plate required
No
Number of potentials 1
Number of levels 1
No. of clamping points per level 2
Number of potentials per tier 1
Levels cross-connected internally Yes
PE connection No
N-function Yes
PE function
No
PEN function No
Additional technical data
Installation advice Terminal rail / mounting
plate
Open sides
closed
Type of mounting Snap-on
CSA rating data
Certificate number (cCSAus) 70128467
Conductors for clamping (rated connection)
Connection direction on side
Type of connection Screw connection
Rating data
Rated AC voltage 1,000 V AC
Rated DC voltage 1,000 V DC
Rated current 125 A
Current at maximum wires
125 A
Standards IEC 60947-7-1, UL 1059
UL rating data
Certificate No. (UR) E60693
