Data sheet



Creation date October 13, 2016 11:49:08 AM CEST

 Catalogue status 12.10.2016 / We reserve the right to make technical changes. 1

SAI-4-M-MVV-M12 S-COD

Weidmüller Interface GmbH & Co. KG

Klingenbergstraße 16

D-32758 Detmold

Germany

Fon: +49 5231 1429-0

Fax: +49 5231 14292083

www.weidmueller.com

General ordering data



Type SAI-4-M-MVV-M12 S-COD

Order No. 1542580000

Version Sensor-actuator passive distributor, M12, Hood

version, Yes

GTIN (EAN) 4050118347326

Qty. 1 pc(s).



Your peripheral devices should be supplied with greater

power. With our new M12 plug-in connector, more

than 250 V and 2 A is possible without problems. The

compact S- and T-coded M12 plug-in connectors are

designed for the transmission of up to 630 V AC or 60 V

DC and 12 A.

Summary of content (4 pages)

PAGE 1
Data sheet SAI-4-M-MVV-M12 S-COD Weidmüller Interface GmbH & Co. KG Klingenbergstraße 16 D-32758 Detmold Germany Fon: +49 5231 1429-0 Fax: +49 5231 14292083 www.weidmueller.com Your peripheral devices should be supplied with greater power. With our new M12 plug-in connector, more than 250 V and 2 A is possible without problems. The compact S- and T-coded M12 plug-in connectors are designed for the transmission of up to 630 V AC or 60 V DC and 12 A. General ordering data Type Order No.
PAGE 2
Data sheet SAI-4-M-MVV-M12 S-COD Weidmüller Interface GmbH & Co. KG Klingenbergstraße 16 D-32758 Detmold Germany Fon: +49 5231 1429-0 Fax: +49 5231 14292083 www.weidmueller.com Technical data Dimensions and weights Net weight 200 g Temperatures Operating temperature -20 - 80°C General data Connection type PE Fire behaviour No.
PAGE 3
Data sheet SAI-4-M-MVV-M12 S-COD Weidmüller Interface GmbH & Co. KG Klingenbergstraße 16 D-32758 Detmold Germany Fon: +49 5231 1429-0 Fax: +49 5231 14292083 www.weidmueller.com Drawings Dimensioned drawing Wiring diagram Printing Creation date October 13, 2016 11:49:08 AM CEST Catalogue status 12.10.2016 / We reserve the right to make technical changes.
PAGE 4
Data sheet SAI-4-M-MVV-M12 S-COD Weidmüller Interface GmbH & Co. KG Klingenbergstraße 16 D-32758 Detmold Germany Fon: +49 5231 1429-0 Fax: +49 5231 14292083 www.weidmueller.com Accessories Pin Your peripheral devices should be supplied with greater power. With our new M12 plug-in connector, more than 250 V and 2 A is possible without problems. The compact S- and T-coded M12 plug-in connectors are designed for the transmission of up to 630 V AC or 60 V DC and 12 A. General ordering data Type Order No.
