Data Sheet

Data sheet

ModuPlug
HDC MDU
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 16
D-32758 Detmold
Germany
Fon: [phone]
Fax: [phone]
www.weidmueller.com
Technical data


Creation date May 27, 2019 2:09:19 PM CEST
 Catalogue status 23.05.2019 / We reserve the right to make technical changes. 2
Dimensions and weights

Width 7.15 mm

Width (inches) 0.281 inch
Height 20.6 mm

Height (inches) 0.811 inch
Depth 34 mm

Depth (inches)
1.339 inch
Net weight 2.62 g



Temperatures

Limit temperature -40 °C ... 125 °C
 

General data

Insulation strength
10
12
Ω

Material Polycarbonate, glass fibre
reinforced
Plugging cycles ≥ 500

Pollution severity 3
Required plug-in slots 0.5

Series
ModuPlug
UL 94 flammability rating V-0



Classifications

ETIM 6.0 EC002312

eClass 6.2 27-14-34-19
eClass 9.0 27-44-02-92

eClass 9.1 27-44-02-18

Approvals

ROHS Conform

Downloads

Brochure/Catalogue CAT 3 HDC 17/18 EN
FL FIELDWIRING EN
Engineering Data EPLAN
Engineering Data STEP

