INSTALLATION Continued
F If this test fails, try changing com ports on the communication program until you
find the correct port. When a working com port is found, repeat the above test
starting at step 1.
# Tool Tip: With some communication programs, any change made to the program
settings requires you to save the changes, exit the program and restart the
program.
 NOTE: If you find that a failure is traced to the receiver and ALL receiver
troubleshooting has failed contact the receiver manufacture.
Connecting the DSC-20 to your computers serial port
•
Connect one end of the supplied modular cable to J5 (Computer) on the DSC-20
and the other end to the male D-Sub to modular adapter labeled “S-9”.
•
Plug the female D-Sub modular “S-9” adapter into your computers serial port.
•
Press the space bar ONCE and the configuration menu will appear.
The pin out of the modular/D-Sub adapters is shown below.
RJ-11
Adapter
Pin
Number.
DB-9 “V-9”
Male. Pin
Number.
StarGuide
II/III M & C
port
DB-9 “S-9”
Female. Pin
Number.
“Remote”
DSC-20 point
of view.
Function Name.
4 2 3 RS-232 Receive
3 3 2 RS-232 Transmit
2 5 5 Ground
Installation and Operation Manual
Broadcast Tools, Inc.
Page 9
