User guide

In this chapter

 Menu Bar

 Placing Zones

 Measuring Zones

Aer you have congured the lanes and stop bars, click on tab 2 to congure the zones and

channels. e Zones & Channels screen allows you to place zones and congure detection

channels (see Figure 8.1).

Figure 8.1 – Zones & Channels Tab

Each Matrix sensor supports up to 16 zones and 16 channels. If unused, the 16 zones are

stacked outside the sensor view and labeled Z1–Z16.

Zones & Channels 8
