6 INTRODUCTION SMARTSENSOR MATRIX USER GUIDE
ration process is quick and easy. Aer installation, the sensor will require little or no on-site
maintenance and can be remotely congured.
is user guide outlines the step-by-step process of installing and conguring the Smart-
Sensor Matrix. Any questions about the information in this guide should be directed to
Wavetronix or your distributor.
SmartSensor Matrix Package
A standard SmartSensor Matrix package may contain the following items:
SmartSensor Matrix detector(s) with installed sensor backplate
Sensor mounting kit(s)
SmartSensor 6-conductor cable(s)
Intersection preassembled backplate
Click 112/114 detector rack card(s) with patch cable(s)
Click 104 four-channel DIN rail contact closure module
SmartSensor Manager Matrix (SSMM) soware
SmartSensor Matrix User Guide
Note
Instead of the intersection preassembled backplate, you may be using the Click 600
cabinet interface device, the preassembled 19-inch rack, or the segmented preas-
sembled backplate. The coming chapters will note installation dierences between
these devices and the preassembled backplates where applicable.
SmartSensor Matrix system options include (see Figure I.2):
AC power conversion – Provides reliable power for the sensors and backplate com-
ponents. is option is normally recommended instead of the DC surge protection
because it will not burden the existing DC power modules.
Remote IP connection – Provides a way (via a Click 301 serial to Ethernet converter)
to connect to the sensor from a remote location. e Click 301 is recommended for
remote management.
