58 CHAPTER 5  COMMUNICATION
Note
To configure channels for a future installation, connect using a virtual connection,
create a virtual sensor file and then back up the configuration settings that you cre-
ated. After the file is successfully backed up, the virtual sensor file will change to a
sensor setup file and can be restored to any sensor in the field.
When a connection is made to the SmartSensor Matrix, the main menu will appear and all
conguration options will become available (see Figure 5.9).
Figure 5.9 – Main Menu (Connected)
Viewing Connection Information
Once connected, you can view additional information about the connection you have es-
tablished by clicking on the moving arrows icon on the top right of the main menu page or
on the bottom right of the Communication screen (see Figure 5.10). ese arrows are only
visible when there is an established connection.
Figure 5.10 – Connection Info Screen
