Appendix A – Cable Connector Definitions
e connector end of the SmartSensor 6-conductor cable mates to the 8-pin connector on
the SmartSensor Matrix (see Figure A.1).
A
B
C
D
E
F
G
H
Figure A.1 – SmartSensor Matrix Connector
e SmartSensor 6-conductor cable has seven wires. Table A.1 details the pinout of the
