Introduction In this chapter ˽˽ SmartSensor Matrix Package ˽˽ Selecting a Mounting Location The Wavetronix SmartSensor Matrix™ is a stop bar presence detector designed for use at signalized intersections (see Figure I.1). The SmartSensor Matrix detects vehicles through the use of a 24.125 GHz (K band) operating radio frequency. Using what is classified as frequency modulated continuous wave (FMCW) radar, SmartSensor Matrix detects and reports vehicle presence in as many as 10 lanes simultaneously.
6 INTRODUCTION • SMARTSENSOR MATRIX USER GUIDE ration process is quick and easy. After installation, the sensor will require little or no on-site maintenance and can be remotely configured. This user guide outlines the step-by-step process of installing and configuring the SmartSensor Matrix. Any questions about the information in this guide should be directed to Wavetronix or your distributor.
INTRODUCTION • SMARTSENSOR MATRIX USER GUIDE Control Bridge to Rack Cards AC Power Conversion Option Control Bridge on T-bus Configuration Toolkit (attach to T-bus) Remote IP Connection Option (attach to T-bus) Figure I.2 – SmartSensor Matrix System Options Control Bridge to Sensors Note SmartSensor Matrix systems provide a control bridge to manage all connected SmartSensor and Click devices.
INTRODUCTION • SMARTSENSOR MATRIX USER GUIDE 140 ft 8 Sensor Pole 140 ft Figure I.3 – Corner Radar ˽˽ Line of sight – Position the sensor so that it will be able to detect the entire area of interest. Avoid occlusion by installing the sensor away from trees, signs and other roadside structures. ˽˽ Detection coverage – Position the sensor so that it will be able to reach all the specified stop bar detection zones.
INTRODUCTION • SMARTSENSOR MATRIX USER GUIDE signs or other flat surfaces directly behind it. This will help reduce multiple reflection paths from a single vehicle. ˽˽ Cable length – Make sure that you have sufficient homerun and sensor cabling. Cable runs as long as 500 ft. (152.4 m) can be achieved using 24 VDC operation and the system’s native RS-485 communications. If your application requires a cable length longer than 500 ft. (152.4 m), contact Wavetronix Technical Services for assistance.
Part I Installing the SmartSensor Matrix Chapter 1 – Installing the SmartSensor Matrix Chapter 2 – Connecting Power and Surge Protection Chapter 3 – Contact Closure Communication
Installing the SmartSensor Matrix 1 In this chapter ˽˽ ˽˽ ˽˽ ˽˽ ˽˽ ˽˽ ˽˽ Sensor Mounting Guidelines Attaching the Mount Bracket to the Pole Attaching the Sensor to the Mount Bracket Aligning the Sensor to the Roadway Applying the Silicon Dielectric Compound Connecting the SmartSensor 6-conductor Cable Grounding the Sensor 1 The installation process includes attaching the mounting bracket to the pole; attaching the sensor to the mounting bracket; aligning the sensor; applying a silicon dielectric compou
14 CHAPTER 1 • INSTALLING THE SMARTSENSOR MATRIX Warning Use caution when installing any sensor on or around active roadways. Serious injury can result when installation is performed using methods that are not in accordance with authorized local safety policy and procedures. Always maintain an appropriate awareness of the traffic conditions and safety procedures as they relate to specific locations and installations.
CHAPTER 1 • INSTALLING THE SMARTSENSOR MATRIX ˽˽ Take into consideration the sensor’s field of view, which reaches 140 ft. (42.7 m) from the sensor. Place the sensor so that the field of view covers all the areas of interest. ˽˽ The mast arm is frequently a good place to mount the sensor. ˽˽ The mounting position should have a clear view of the detection area. Poles, mast arms, signal heads, or other objects should not block the view of the detection area.
16 CHAPTER 1 • INSTALLING THE SMARTSENSOR MATRIX One swivel joint is used to pan the sensor field of view left or right and the other swivel joint is used to tilt the sensor down towards the roadway. If you are not using the double swivel-mount, make sure the pole straps are adjustable at this point in the installation process.
Edge of first lane of interest CHAPTER 1 • INSTALLING THE SMARTSENSOR MATRIX 45° 45° Pan sensor towards stop bar Stop Bar Figure 1.3 – Corner Radar Field of View Position To visualize the extent of the sensor field of view, the 90° field of view is imprinted on the top and bottom of the sensor case. If more of a visual indicator is needed, then a square framing tool (e.g. rafter square) or other tool with a right angle can be held above the sensor.
18 CHAPTER 1 • INSTALLING THE SMARTSENSOR MATRIX 1 2 3 Adjust the side-to-side angle so that the front edge of the field of view provides a view downstream of the stop bar. Tilt the sensor down so it is aimed at the center of the lanes of interest. If necessary, rotate the sensor so that the bottom edge of the sensor is parallel with the roadway. This is necessary where the intersection approach has a significant grade.
CHAPTER 1 • INSTALLING THE SMARTSENSOR MATRIX Figure 1.6 – Sensor 6-conductor Cable Connector To set up your network in an orderly fashion, it is recommended that labeling be used on the service end of each SmartSensor 6-conductor cable. A convenient way to label the cables is to mark the last seven digits of the serial number on each sensor and the direction of traffic monitored (see Figure 1.7). Figure 1.
Connecting Power and Surge Protection 2 In this chapter ˽˽ ˽˽ ˽˽ ˽˽ Mounting the Backplate Connecting AC Power Providing System Surge Protection Terminating SmartSensor 6-conductor Cables 2 After installation, each SmartSensor Matrix will need to be integrated into the main traffic cabinet for power and surge protection.
22 CHAPTER 2 • CONNECTING POWER AND SURGE PROTECTION Figure 2.1 – Intersection Preassembled Backplate Mounting the Backplate Use the following steps to mount the backplate in the traffic cabinet: 1 2 Locate the area planned for mounting the backplate. The backplate can usually be mounted on the side panel of a NEMA-style cabinet. Attach the backplate with the U-channel mounting screws.
CHAPTER 2 • CONNECTING POWER AND SURGE PROTECTION Warning Make sure power to AC mains is disconnected while wiring the AC input. If your installation does not require AC power, you will need to use surplus DC power inside the traffic cabinet. In this case, Wavetronix recommends you use the Click 221 (8 A DC surge protector) to protect the backplate and SmartSensor Matrix units from DC surges. See Appendix C for information regarding the Click 221. Figure 2.
24 CHAPTER 2 • CONNECTING POWER AND SURGE PROTECTION Caution An authorized electrical technician should install the preassembled backplate. Persons other than authorized and approved electrical technicians should NOT attempt to connect the backplate to a power supply and/or traffic control cabinet, as there is a serious risk of electrical shock through unsafe handling of the power source. Extreme caution should be used when connecting the backplate to an active power supply.
CHAPTER 2 • CONNECTING POWER AND SURGE PROTECTION Follow the steps below to provide a low impedance protective earth connection: 1 2 Connect one end of a protective earth ground wire to the bottom of the PE terminal block. A 10 AWG stranded wire is recommended for protective earth ground connections and is also the largest that will fit in the terminal block. Connect the other end of the protective earth ground wire to a protective earth screw terminal within the main traffic cabinet.
26 CHAPTER 2 • CONNECTING POWER AND SURGE PROTECTION +24V DC -DC +RS-485 -RS-485 GND Power (red wire ) ( black wire ) Green Gray Green RS-485 Figure 2.5 – T-bus Pinout Diagram Providing System Surge Protection The Click 222 system surge protector is designed to prevent electrical surges conducted along underground cables from damaging the cabinet equipment (see Figure 2.6). Figure 2.
CHAPTER 2 • CONNECTING POWER AND SURGE PROTECTION ˽˽ TD – Indicates when data is transmitted over the T-bus or over the control bridge. This LED does not indicate data transmitted on the A or B ports. ˽˽ RD – Indicates when data is received over the T-bus or over the control bridge. This LED does not indicate data received on the A or B ports. Note If the DC Surge OK LED is not on when the Click 222 is powered, call Wavetronix Technical Services for assistance.
28 CHAPTER 2 • CONNECTING POWER AND SURGE PROTECTION Port A & Port C x OUT x x x x x x x x x x x x x x x x PWR GND 485+ 485- 485+ 485- DRN IN x x x x x x x x x x OUT x x x x x x IN x x x x x x x x x PWR GND 485+ 485- 485+ 485- DRN x Port B & Port D OUT x x x x x x x PWR GND 485+ 485- 485+ 485- DRN SSMatrix #4 x x Port A & Port C SSMatrix #3 x OUT SSMatrix #2 x x x PWR GND 485+ 485- 485+ 485- DRN IN Port B & Port D IN x x x x x x
CHAPTER 2 • CONNECTING POWER AND SURGE PROTECTION Note Do not strip the service end of the cable until after it has been routed through conduit. The cable should be one continuous run without any splices. Use the steps below to land the sensor cables: 1 2 3 4 After routing your SmartSensor 6-conductor cable into the cabinet, carefully strip back the cable jacket and shielding on the service end of the cable.
Contact Closure Communication 3 In this chapter ˽˽ ˽˽ ˽˽ ˽˽ ˽˽ Using the Click 112/114 DIP Switches Using the Click 104 Rotary Switch Attaching and Programming the Click 112/114 Attaching and Programming the Click 104 Channel Mapping 3 Each SmartSensor Matrix communicates with standard traffic cabinets using either the Click 104 DIN rail contact closure module or the Click 112/114 detector rack cards (see Figure 3.1).
32 CHAPTER 3 • CONTACT CLOSURE COMMUNICATION Note See the Click 100–400 Series User Guide for complete information on how to connect and configure the Click 104 DIN rail contact closure module and the Click 112/114 detector rack cards. Each SmartSensor Matrix could potentially use up to 16 channels using a combination of Click 104/112/114 contact closure modules. This means that a standard four-approach stop bar detection system can be accommodated by a 64-channel detector rack.
CHAPTER 3 • CONTACT CLOSURE COMMUNICATION Note An advantage of using the DIP switches for configuration is that if you ever need to replace a Click 112/114, you can simply set the DIP switches on the new card to match the pattern of the DIP switches on the card you are replacing, then slide the new one into the same slot in the detector rack. Click 114 Input Mapping DIP Switch Settings On a Click 114, channel group 1 comprises input channels 1–4.
34 CHAPTER 3 • CONTACT CLOSURE COMMUNICATION Input Mapping Switches Baud Rate Switches S4 S5 4 1 2 3 3 5 6 7 8 Channel Group 1 2 On 6 4 Bus 1 5 7 8 Off Bus 2 Click 112 –Selects channels 1 & 2 Figure 3.4 – Click 112 DIP Switches for Channels 1 and 2 Figure 3.5 shows how to set the DIP switches on the Click 112 on the right. This will assign sensor output channels 3 and 4 for output.
CHAPTER 3 • CONTACT CLOSURE COMMUNICATION As shown in the table below, the outputs are mapped sequentially—that is, they can only be mapped in numerically ordered groups of four (1–4, 5–8, etc.). If you set the switch to 3, for 9–12, then sensor channel 9 would be mapped to output 1, sensor channel 10 would be mapped to output 2, sensor channel 11 would be mapped to output 3, and sensor channel 12 would be mapped to output 4.
36 CHAPTER 3 • CONTACT CLOSURE COMMUNICATION 4 5 6 7 Connect a 6-ft. (1.8-m) patch cord from the Click 222 RS-485 B port to a bus 1 port on another rack card. If you are using Click 112 cards, use an 6-in. (15-cm) patch cord to share bus 1 between cards dedicated to the same sensor. Also, configure one card to use Matrix channels 1 and 2 and configure the other card to use Matrix channels 3 and 4.
CHAPTER 3 • CONTACT CLOSURE COMMUNICATION Detection Channel Menu Level 2 Menu Level 1 Mode Switch Figure 3.7 – Click 112/114 Menu Normally, a SmartSensor Matrix sensor will send 10 contact closure messages each second. If a rack card does not receive communications from a sensor within 10 seconds, the rack card will go into fail-safe mode and all of the contact closures will be activated and the corresponding detection channel LEDs on the faceplate will turn on.
38 CHAPTER 3 • CONTACT CLOSURE COMMUNICATION 3 If needed, daisy-chain multiple Click 104 devices together by utilizing both RJ-11 jacks on each device’s faceplate. Click 104 LEDs The front panel of the device features a push-button and three banks of LEDs for on-device configuration and monitoring. The first bank of LEDs, labeled Channel, displays the state of the contact closure outputs (see Figure 3.8). 1 Channel 2 3 Menu 4 PWR OK TD RD Figure 3.
CHAPTER 3 • CONTACT CLOSURE COMMUNICATION 4 5 6 menu option. Press and hold the mode switch to cycle through the submenu. The Level 2 LEDs will light to indicate that the device is cycling though all configuration options. Release the mode switch once the desired configuration option is reached. Quickly press and release the mode switch to select the current configuration option.
40 CHAPTER 3 • CONTACT CLOSURE COMMUNICATION NEMA TS2, 2070 and other advanced traffic cabinet systems usually allow software programming of the detector card channel outputs to traffic phases via a channel-to-phase mapping grid in the controller menu. Figure 3.9 illustrates how the detector channels 1 to 16 of a NEMA TS-2 rack can be assigned to the standard eight phases using four Click 114 cards.
Part II Using SmartSensor Manager Matrix Chapter 4 – Installing SmartSensor Manager Matrix Chapter 5 – Communication Chapter 6 – Sensor Settings Chapter 7 – Lanes & Stop Bars Chapter 8 – Zones & Channels Chapter 9 – Verification Chapter 10 – Tools
Installing SmartSensor Manager Matrix 4 In this chapter ˽˽ Using the Install Kit ˽˽ Installing SSMM ˽˽ Microsoft .NET Framework 4 The SmartSensor Manager Matrix (SSMM) software enables you to configure and interact with the SmartSensor Matrix. SSMM can be run on a Windows® PC and on a Socket Mobile 650 handheld computer. The software comes preloaded on the handheld computer included with the Wavetronix Install Kit; it can also be downloaded on other computers by going to www.wavetronix. com.
46 CHAPTER 4 • INSTALLING SMARTSENSOR MANAGER MATRIX Wireless or Wired Figure 4.1 – Install Kit The Click 421 converts wired or wireless serial data to RS-485 communication and sends it to all devices on a shared multi-drop communication bus on the backplate. This allows control of all SmartSensor Matrix units from a single access point.
CHAPTER 4 • INSTALLING SMARTSENSOR MANAGER MATRIX software guidelines on how to discover Bluetooth devices and configure a Bluetooth serial connection. The install kit also includes an RJ-11 patch cord with a pigtail on one end. The pigtail can be wired to the RS-485 screw terminal on the Click 421 and used to patch into RJ-11 sockets on the rack cards or backplate for troubleshooting.
48 CHAPTER 4 • INSTALLING SMARTSENSOR MANAGER MATRIX Figure 4.3 – Location to be Installed 5 6 Click the Install Now button. After SSMM is installed, you can create shortcuts to the SSMM software on the desktop and in the Start menu using the corresponding checkboxes (see Figure 4.4). If no shortcuts are desired, uncheck the corresponding boxes. Figure 4.4 – Shortcut Options 7 8 Click the View release notes when finished checkbox to view the SSMM release notes.
CHAPTER 4 • INSTALLING SMARTSENSOR MANAGER MATRIX nix Install Kit (see the Using the Install Kit section earlier in this chapter), which includes a Socket Mobile SoMo 650 handheld computer that comes preconfigured with SmartSensor Manager Matrix, as well as Click Supervisor and the Manager software programs for the other Wavetronix sensors. These software programs are tested for and supported on the SoMo 650. SSMM can also be installed and may function on a handheld computer other than the SoMo 650.
50 CHAPTER 4 • INSTALLING SMARTSENSOR MANAGER MATRIX Framework v3.5 is installed on your PC. If it is not installed, you will be prompted to install it (see Figure 4.7). Figure 4.6 – Microsoft .NET Framework V2.0 Prompt Click the Install Framework button and you will be taken to the Microsoft Website where you can install the latest version of Microsoft .NET Framework.
Communication 5 In this chapter ˽˽ ˽˽ ˽˽ ˽˽ ˽˽ Serial Connection Internet Connection Virtual Connection Viewing Connection Info Upgrading the Sensor's Embedded Software 5 Once the sensors are installed, use the SSMM software to change settings, view data and configure the sensors to the roadway. Launch SSMM by either clicking on the icon that was placed on your desktop or clicking the icon found in the Start menu. The SSMM splash screen and then main screen shown in Figure 5.1 will appear.
52 CHAPTER 5 • COMMUNICATION Figure 5.1 – SSMM Splash Screen (left) and Main Screen (right) You can always view the version of SSMM you are using by right-clicking (click and hold on handheld) on the main screen and then clicking SSM Matrix Version. To see the version, date and timestamp of the individual components that make up the program, select Component Version (see Figure 5.2). Figure 5.
CHAPTER 5 • COMMUNICATION Figure 5.3 – Firmware Versions (left) and Hardware Versions (right) If you are using SSMM on a computer, you can use the panel in the lower left of the main screen to change the size of the user interface on your computer. Click any of the three squares to increase or decrease the size of the user interface. The first step is to make a connection to the sensor.
54 CHAPTER 5 • COMMUNICATION Note A quick search should not be used the first time you connect to sensors on an RS-485 control bus. If you add or replace a sensor on an existing control bus, a full search will need to be performed before a quick search can be made. Note If you perform a full search and then cancel before the search is complete, the sensors not discovered before the full search was terminated will also not be visible after a quick search.
CHAPTER 5 • COMMUNICATION be set to default values. Note It is recommended that you label the service end of each SmartSensor Matrix cable when the cable is pulled so that the approach the sensor is monitoring can be documented. You may need to power down all sensors except for the one you are configuring in order to determine which approach it is monitoring. If you have problems connecting: 1 2 Make sure that all power and communication wiring is correct. Check the port settings (Port ID).
56 CHAPTER 5 • COMMUNICATION This field is not editable from this screen. ˽˽ Sensor Version – Overall sensor product version, which represents a released combination of the DSP, Algorithm, FPGA and FPAA subcomponent versions. ˽˽ DSP Rev – DSP code version date (YYYY-MM-DD). ˽˽ Algorithms Rev – Algorithm code version date (YYYY-MM-DD). ˽˽ FPGA Version – FPGA version date (YYYY-MM-DD). ˽˽ FPAA Version – FPAA version date (YYYY-MM-DD).
CHAPTER 5 • COMMUNICATION Figure 5.6 – Internet Connection Screen 3 4 5 6 7 8 Enter the IP address or URL of the sensor of interest. Enter the IP address assigned to either the CDMA modem or the Click 301 serial to Ethernet converter. Enter the port number assigned to the CDMA modem or the Click 301 serial to Ethernet converter in the Port field. This will be an integer value in the range of 0–65536. The Click 301 port number automatically defaults to 10001. Set the Timeout value to 1000.
58 CHAPTER 5 • COMMUNICATION 9 Click the Connect button. When a connection is established you will be directed back to the home page. If you have problems connecting: 1 2 Make sure that all power and communication wiring is correct. Check the address and port number. Connection failure can occur for various reasons; if a failure occurs repeatedly, call Wavetronix Technical Support at 801-764-0277 for assistance.
CHAPTER 5 • COMMUNICATION ˽˽ To review how the software works Use the following steps to make a virtual connection: 1 2 Click the Communication button. Select the Virtual tab (see Figure 5.9). Figure 5.9 – Virtual Connection Screen 3 4 5 6 Select or create a virtual sensor file (.vsf ) by clicking the magnifying glass icon. Click the Search button. This may take up to 30 seconds while the sensors on your virtual control bus are discovered and listed.
60 CHAPTER 5 • COMMUNICATION Virtual sensor files can be converted to sensor setup files and can be restored to an actual sensor; sensor setup files that have been backed up from a sensor can also be converted to virtual sensor files. To convert a sensor setup file to a virtual sensor file, make a virtual connection and then use the Restore Sensor Setup tool in the Tools menu. To convert a virtual sensor file to a sensor setup file, use the Back-up Sensor Setup tool.
CHAPTER 5 • COMMUNICATION Figure 5.11 – Connection Info Screen Below is a list of the information available on the Connection Info screen: ˽˽ ˽˽ ˽˽ ˽˽ ˽˽ Status – Shows that you are connected. Sensor – Shows the subnet and sensor ID. Type – Shows the type of connection. Duration – Shows how long you have been connected. Failures – Shows the amount of failures during the connection, the percentage rate of failure and a link to the communication error log.
62 CHAPTER 5 • COMMUNICATION Figure 5.12 – Error Log Upgrading the Sensor’s Embedded Software After clicking the Connect button, the software will check to see if your software version matches the version of the sensor’s embedded software. If a discrepancy is detected, the Version Control screen may appear asking you to install firmware upgrades (see Figure 5.13).
CHAPTER 5 • COMMUNICATION Click the Details button to view the firmware versions of both the SSMM software and the SmartSensor Matrix. Once the Version Control screen appears, you can do one of the following: ˽˽ Upgrade the sensor’s embedded software by clicking the UPLOAD FIRMWARE button. ˽˽ Click the Close button and continue the configuration process. ˽˽ Find the version of SSMM software that is compatible with the sensor’s embedded software.
64 CHAPTER 5 • COMMUNICATION your sensor configuration. Follow the steps in the back up message to back up your sensor's configuration. Note If you are upgrading the software, it is always a good idea to back up your sensor configuration. There is always a chance that the sensor conguration could be lost after upgrading. You can create a back up file by going to the Tools screen (see Chapter 10). Click the UPLOAD FIRMWARE button to install the firmware embedded in SSMM onto the SmartSensor Matrix.
6 Sensor Settings In this chapter ˽˽ Sensor Settings Screen ˽˽ Sensor Info Screen 6 Click the Sensor Settings link on the main menu to change and save settings on the sensor. General Sensor Settings The General tab of the Sensor Settings screen allows you to change the sensor description, RF channel, wash-out time, and other settings (see Figure 6.1). Figure 6.
66 CHAPTER 6 • SENSOR SETTINGS The General tab contains the following fields: ˽˽ Serial Number – Contains the sensor serial number and cannot be edited. ˽˽ Sensor ID – Contains the ID used to uniquely identify all sensors on a multi-drop bus. This ID is the last seven digits of the sensor’s serial number and cannot be edited. ˽˽ Description – Allows you to enter a description for each sensor. Limited to 64 characters. ˽˽ Location – Allows you to enter the intersection location of the sensor.
CHAPTER 6 • SENSOR SETTINGS to quickly change transmission direction. The default value is 10 milliseconds. This value can be selected for both of the sensor’s ports independently. Note In many cases, SSMM will be connected over port 1. A green arrow is used to show the port over which SSMM is connected to the sensor. During troubleshooting or other special cases, you may want to connect to the sensor over port 2.
68 CHAPTER 6 • SENSOR SETTINGS Figure 6.
Lanes & Stop Bars 7 In this chapter ˽˽ ˽˽ ˽˽ ˽˽ Display Options Menu Bar Automatic Configuration Manual Configuration 7 After Sensor Settings, the next option available from the main menu is Sensor Setup. When you click this option, the first screen that appears is Lanes & Stop Bars. The Lanes & Stop Bars screen shows the sensor’s 100-ft. (30.5-m), 90° degree view and provides automatic and manual controls to quickly and easily configure the sensor to the roadway.
70 CHAPTER 7 • LANES & STOP BARS Vehicle detections are represented by tracks (a series of dots) along the sensor’s view. The vehicle tracks show where the sensor is detecting traffic and will later help you configure lanes. Vehicle track history can be cleared from the screen by clicking the Clear Tracks button below the sensor view. Note Vehicle tracks are not constrained to lanes, even after you have saved a lane configuration to the sensor.
CHAPTER 7 • LANES & STOP BARS The Edit Area also contains the approach name in a small window outside of the sensor’s view (see Figure 7.3) If needed, click on the name box to see the entire approach name. This allows you to always know which approach is being configured. The approach name can be edited in the Sensor Settings window. Figure 7.3 – Approach Name Saved Configuration Overlay The Saved Configuration overlay shows everything that has been saved to the sensor (see Figure 7.4).
72 CHAPTER 7 • LANES & STOP BARS Figure 7.5 – Automatic Configuration Overlay SmartSensor Matrix is constantly running the auto-configuration process in order to find undiscovered lanes and stop bars. During this process, lanes will appear in the Auto Cfg overlay. You will need to select and capture auto-configured lanes in order to save them to the sensor (see the Capturing Lanes and Stop Bars section below). Wait at least 2–3 cycles of the intersection to accurately detect the lanes and stop bars.
CHAPTER 7 • LANES & STOP BARS Note If a stop bar is found for a lane during the auto-configuration process, it will be captured with the lane. Menu Bar The menu bar at the bottom of the screen allows you to perform a variety of operations during sensor configuration. Click the button at the right side of the menu bar to open a window that shows descriptions for the various menu icons (see Figure 7.7). Figure 7.
74 CHAPTER 7 • LANES & STOP BARS Figure 7.8 – Save Changes Dialog Moving the Sensor View The SSMM software shows the position of the SmartSensor Matrix and the view is drawn from the perspective of the sensor. The sensor’s default position is in the bottom-left corner of the display. If the perspective in the software does not match your perspective of the roadway, click the Rotate View button until the sensor position matches the approach you are configuring.
CHAPTER 7 • LANES & STOP BARS Note After you have mounted and aligned the sensor, you should always reboot the sensor so that thresholds can adjust to the current view. Editing Thresholds Warning You should only edit the Matrix thresholds under the direction of Wavetronix Technical Services. If you believe that you need to adjust the thresholds, please call Wavetronix at 801-734-7200 for assistance. 1 2 Click on the Edit Thresholds button.
76 CHAPTER 7 • LANES & STOP BARS Figure 7.11 – Zoom In Feature After you click on Adjust Bins or Adjust All, the Sensitivity Slider window will appear (see Figure 7.12). Click on the up/down buttons to change the sensitivity (in decibels). Negative values will lower the rejection threshold in order to increase sensitivity; positive values will increase the rejection threshold in order to decrease sensitivity. Figure 7.
CHAPTER 7 • LANES & STOP BARS Manual Configuration After the automatic configuration process is complete, manual adjustments can be made to fine-tune the sensor configuration. In some cases, it will be easier to configure the sensor manually than to use the auto-configured lanes and stop bars.
78 CHAPTER 7 • LANES & STOP BARS Figure 7.15 – Moving Lane Outside Edit Area Inserting/Deleting/Moving a Stop Bar To insert a lane stop bar: 1 2 3 Select a lane in the edit area. Click on the selected lane again to bring up the Edit Lane window (see Figure 7.14). Click on the Insert Stop Bar option of the Edit Lane window. To delete a lane stop bar: 1 2 Select a lane in the edit area. Click on the Delete Stop Bar option of the Delete Stop Bar window (see Figure 7.16). Figure 7.
CHAPTER 7 • LANES & STOP BARS To delete a lane node: 1 2 3 Select a lane in the edit area. Click on the selected lane in the vicinity of the desired node to bring up the Node Adjustment window (see Figure 7.17). Click on the Delete Node option. Figure 7.17 – Node Adjustment Window Moving a Lane Node 1 2 Select a lane in the edit area. Click and drag the lane node to the desired location (see Figure 7.18).
80 CHAPTER 7 • LANES & STOP BARS Adjusting the Width of a Lane Node Adjusting the width of a lane node will adjust the width of the lane. 1 2 3 Select a lane in the edit area. Click on the selected lane and then click again on the node that will be adjusted and the Edit Node window will appear. Change the width (in feet) of the node, by clicking the Width up/down buttons or enter the desired node width in the Width field. Adjusting the node width will impact detection search area for that lane.
Zones & Channels 8 In this chapter ˽˽ Menu Bar ˽˽ Placing Zones ˽˽ Measuring Zones 8 After you have configured the lanes and stop bars, click on tab 2 to configure the zones and channels. The Zones & Channels screen allows you to place zones and configure detection channels (see Figure 8.1). Figure 8.1 – Zones & Channels Tab Each Matrix sensor supports up to 16 zones and 16 channels. If unused, the 16 zones are stacked outside the sensor view and labeled Z1–Z16.
82 CHAPTER 8 • ZONES & CHANNELS When you enter the Zones & Channels tab and you haven't yet configured any zones, you will be prompted to add auto zones (see Figure 8.2). If you click Yes, a zone will be placed in each configured lane. Lanes and stop bars must be defined before you can add auto zones. Note Lanes and stop bars must be defined and saved before you will be able to add auto zones. Figure 8.
CHAPTER 8 • ZONES & CHANNELS Figure 8.3 – Zones & Channels Menu Bar The Zones & Channels menu bar contains the following options: ˽˽ ˽˽ ˽˽ ˽˽ ˽˽ ˽˽ ˽˽ ˽˽ To Main Menu – Returns you to the main menu. Save Config – Saves the zones and channel mapping to the sensor. Undo Changes – Undoes changes made to the zones and channels. Edit Zone – Allows you to move a zone and specify the channels to which it is mapped. Zone/Channel Map – Allows you to map zones to channels.
84 CHAPTER 8 • ZONES & CHANNELS Editing Zones Click the Edit Zone button to adjust the currently selected zone. An entire zone can be moved by clicking and dragging or by using the arrow buttons on the Edit Zone window (see Figure 8.5). Zones can overlap each other. Figure 8.5 – Edit Zone Window Placing AutoZones Click the Place Auto Zones button if you would like to replace your manually configured zones with auto zones.
CHAPTER 8 • ZONES & CHANNELS Normal Channel The normal channel detects presence in the zone. This means that as soon as the leading edge of the vehicle breaks the plane of the leading edge of the zone, the channel will be activated (see Figure 8.7). Pulse Channel LED Channel LED Channel LED Figure 8.7 – Normal Channel If there are no delay or extend settings, the zone will remain activated until all cars have exited the zone.
86 CHAPTER 8 • ZONES & CHANNELS Pulse Channel LED Channel LED Channel LED Figure 8.9 – Pulse Channel Even though the zone stays activated, the contact closure call will only stay on for the time specified in the pulse channel width setting. You can verify the duration of the pulse channel calls by viewing the virtual LEDs in the SSMM software. Once you have selected the pulse channel type, the extend setting will be disabled. Note A pulse channel may be difficult to view in the SSMM software.
CHAPTER 8 • ZONES & CHANNELS Figure 8.10 – Zone/Channel Map Window Each channel column contains channel number and channel type (N=normal, C=count, P=pulse). Click on the individual zones in the zone column to highlight the zones in the edit area. Editing Channels The Edit Channel button will allow you to choose the channel type, map/un-map zones to a selected channel, and change delay/extend settings (see Figure 8.11).
88 CHAPTER 8 • ZONES & CHANNELS Figure 8.12 – Output Settings (Normal, Counting, Pulse) ˽˽ Detector Input – The Detector Input number provides a way for you to map inputs to the intersection phase in the controller. By default, the Detector Input will be set to “00;” if the input is left at “00,” then it is unassigned. This setting is for reference purposes only and does not actually change the sensor.
CHAPTER 8 • ZONES & CHANNELS The dashes in the table mean that those particular settings are disabled due to the selected channel type. Double click on any channel row to change the output settings for that channel. Measuring Zones The SSMM software contains a feature that allows you to see how large a zone is as well as a number of other distance measurements.
90 CHAPTER 8 • ZONES & CHANNELS Figure 8.
9 Verification In this chapter ˽˽ Channel Indicators ˽˽ Verification Menu Bar 9 After the configuration is complete, you will need to verify that the sensor was configured correctly. To verify lane configuration and channel mapping, click on tab 3. This will bring up the Verification window (see Figure 9.1). Figure 9.1 – Verification View In the Verification window, vehicle detections will appear as light blue rectangles.
92 CHAPTER 9 • VERIFICATION Vehicle detections in a stopped queue are represented by a stationary light blue rectangle. Channel Indicators When detections enter a zone, they will cause the indicators for the channel mapped to that zone to turn red. To see the zones mapped to a particular channel, select that channel by clicking on its indicator (see Figure 9.2). Active zones for the selected channel will be red; inactive zones for the selected channel will be gray.
CHAPTER 9 • VERIFICATION Figure 9.3 – Delay and Extend Zone Settings When vehicles stop before and after a zone, the stopped vehicle queue is extended to fill the space between the two vehicles. This ensures that a queue of vehicles that extends in front and behind a zone will always activate the zone even if the vehicles are not directly over it (see Figure 9.4). Stopped Vehicle Stopped Vehicle Queue Extension Stopped Vehicle Figure 9.
94 CHAPTER 9 • VERIFICATION undo your last edit, edit thresholds and pause/play traffic (see Figure 9.6). Click the button at the right side of the menu bar to see a window with menu descriptions. Figure 9.6 – Verification View Menu Bar The Verification menu bar contains the following options: ˽˽ To Main Menu – Returns you to the main menu. ˽˽ Save Config – Saves the zones and channel mapping to the sensor.
10 Tools In this chapter ˽˽ ˽˽ ˽˽ ˽˽ Backup/Restore Rack Cards Tools Tracker Logging Sensor Self Tests 10 The Tools screen allows you to back up or restore your sensor configuration, log vehicle detections, and perform several other functions (see Figure 10.1). When connected to a sensor, all the options will be active except for the Rack Card Tools option. When a sensor connection is not active, the Rack Card Tools option will be available but the other options will not. Figure 10.
96 CHAPTER 10 • TOOLS Backup/Restore To back up or restore the sensor settings that you have changed, click the Backup/Restore button on the Tools screen (see Figure 10.2). Figure 10.2 – Backup/Restore To create a backup, click on the magnifying glass icon in the Back-up File section. Choose a destination, type in a filename for your new backup and click OK, then click the Back-up Sensor Setup button. Note The backup will appear as an .mxc file.
CHAPTER 10 • TOOLS Rack Cards Tools Access tools for working with rack cards and other contact closure devices by clicking the Rack Card Tools button on the Tools screen when a sensor connection is NOT active (see Figure 10.3). Figure 10.3 – Rack Card Tools The Rack Card Tools screen allows you to verify that you have the correct channel mapping into the traffic controller, without being connected to a sensor.
98 CHAPTER 10 • TOOLS Figure 10.4 – Rack Card Tool Serial Settings 2 3 After you have entered the correct settings, close the Serial Settings window and click the Search button. Once a list of devices appears, click on the desired row. You can identify a device by its ID, Device, Description or Location fields. If you would like to communicate to all the devices, select All Rack Cards in the device column.
CHAPTER 10 • TOOLS Channel Outputs Switch The Channel Outputs toggle switch and 1–16 checkboxes are used to help assist in testing of the rack card outputs. If the Channel Outputs switch is ON, all the selected channel outputs on the Click 112/114 rack card or Click 104 contact closure device will be active. The LEDs that indicate an active output channel will light up accordingly. An output will only be active when the corresponding box is checked.
100 CHAPTER 10 • TOOLS This tool records vehicle detections as shown on the Verification page. Recorded vehicle detections can be used later for playback using a virtual connection. Click on the open folder icon to select a log file. The Select Tracker Log File screen allows you to specify the name of an existing log file or to create a new file (see Figure 10.6). Figure 10.6 – Select Detection Log File Screen Click the ON/OFF toggle switch icon to the ON position to begin logging vehicle detections.
CHAPTER 10 • TOOLS Sensor Self Tests The Sensor Self Tests screen allows you to check the sensor to verify it is working properly (see Figure 10.8). To run the sensor self test, click the Run Sensor Self Tests button. Figure 10.8 – Sensor Diagnostics The test results will appear as either “Success” or “Failed” (see Figure 10.9). If the sensor fails a sensor self test, contact Wavetronix Technical Services for assistance. Figure 10.
Appendix In this chapter ˽˽ Appendix A –Cable Connector Definitions ˽˽ Appendix B –Cable Lengths ˽˽ Appendix D – Click 221 User Reference Guide 11 Appendix A – Cable Connector Definitions The connector end of the SmartSensor 6-conductor cable mates to the 8-pin connector on the SmartSensor Matrix (see Figure A.1). G A H B F C E D Figure A.1 – SmartSensor Matrix Connector The SmartSensor 6-conductor cable has seven wires. Table A.
104 APPENDIX cable connector and the corresponding wire in the cable. The sensor itself also contains internal wires that connect to the protective earth lug. Pin Cable Wire Signal Description A Red DC+ B Orange and white stripe Data bus 485+ (Sensor port 2) C Orange Data bus 485- (Sensor port 2) D Drain / Shield Drain E Blue Control 485- (Sensor port 1) F Blue and white stripe Control 485+ (Sensor port 1) G Black Common (Ground) H ---- Reserved Table A.
APPENDIX receptacle. 9 Press all of the connector parts together. Thread the strain relief onto the back shell. 10 Tighten the strain relief screws on the back. Figure A.2 – Connector Sub-assembly Parts Appendix B – Cable Lengths It is recommended that the sensor be powered by 24 VDC to achieve reliable operation up to 500 ft. (152.4 m) away. Table B.1 lists maximum cable lengths for 12 and 24 VDC. Power Wire Gauge 24 Volts 12 Volts 20 AWG 500 ft. (152.4 m) 90 ft. (27.4 m) Table B.
106 APPENDIX Note This appendix covers the basics of the Click 221. For a full explanation of how to use the Click 221, see the Click Series User Guide. Outgoing DC- voltage onto the T-bus is protected from electrical surges incoming from the DC+ and DC- screw terminals. These terminals do not have reverse-polarity protection, but assumes that all downstream devices will have proper polarity protection. The surge protection meets the IEC 61000-4-S 4KV (Class 4) specification. Figure C.
